Die Compatibility Chart
Refer to www.DEWALT.com for latest tool/die/connector/application compatibility.

WARNING: Always follow the specific manufacturer's installation instructions for crimping tool attachments
being used. It is the installer's responsibility to ensure the compatibility of the cable and connectors used for the crimp.
Failure to follow all instructions and warnings may result in property damage and/or serious personalinjury.

WARNING: Since accessories and dies, other than those offered or recommended by
DeWALT
, have not been tested with
this product, use of such accessories or dies with this tool could be hazardous. To reduce the risk of injury, only
DeWALT
-
recommended accessories and dies should be used with thisproduct.
Recommended accessories and dies for use with your tool are available at extra cost from your local dealer or authorized
service center. If you need assistance in locating any accessory or die, please contact
DeWALT
Industrial Tool Co., 701East
Joppa Road, Towson, MD 21286, call 1-800-4-
DeWALT
(1-800-433-9258) or visit our website: www.dewalt.com.
Connections made with this tool and combination of die and connector families in the chart below create cULus Classified crimps according to the UL
486A-B classification standards.
Copper Short and Long Barrel Lugs and Splices
Die Brand
Die Catalog
Number Cable Size
Connector
Color
Connector
Brand Family Number of Crimps
Burndy U8CRT Copper #8 Red Burndy YA, YA-TC, YA-L,
YA-L-TC, YA-2L,
YA-2LN,
YA-L-2TC, YS, YS-L
1
U5CRT Copper #6 Blue
U4CRT Copper #4 Gray
U3CRT Copper #3 White 2
U2CRT Copper #2 Brown
U1CRT Copper #1 Green
U25RT Copper 1/0 AWG Pink
U26RT Copper 2/0 AWG Black
U27RT Copper 3/0 AWG Orange
U28RT Copper 4/0 AWG Purple 1
U29RT Copper 250 kcmil Yellow
U30RT Copper 300 kcmil White Burndy YA, YA-TC, YA-L,
YA-L-TC, YA-2L,
YA-2LN,
YA-L-2TC, YS, YS-L
2
U31RT Copper 350 kcmil Red
U32RT Copper 400 kcmil Blue
U34RT Copper 500 kcmil Brown
U36RT Copper 600 kcmil Green
U39RT Copper 750 kcmil Black
Greenlee KC12-8 Copper #8 Red 1 Burndy
Coming Soon
Visit
www.DEWALT.
com for most
up to date
compatibility
chart
KC12-6 Copper #6 Blue 1
KC12-4 Copper #4 Gray 1
KC12-2 Copper #2 Brown 1
KC12-1 Copper #1 Green 1
KC12-1/0 Copper 1/0 AWG Pink 1
KC12-2/0 Copper 2/0 AWG Black 1
KC12-3/0 Copper 3/0 AWG Orange 1
KC12-4/0 Copper 4/0 AWG Purple 1
KC12-250 Copper 250 kcmil Yellow 1
KC12-300 Copper 300 kcmil White 2
KC12-350 Copper 350 kcmil Red 2
KC12-400 Copper 400 kcmil Blue 2
KC12-500 Copper 500 kcmil Brown 2
KC12-600 Copper 600 kcmil Green 2
KC12-750 Copper 750 kcmil Black 2
