13
ENGLISH
Protecting the Environment
w
Separate collection. Products and batteries marked
with this symbol must not be disposed of with
normal householdwaste.
Products and batteries contain materials that
can be recovered or recycled reducing the demand for raw
materials. Please recycle electrical products and batteries
according to local provisions. Further information is available at
www.2helpU.com.
Dust Extraction System (Fig. F)
The use of a dust extraction system is recommended to reduce
potentially harmful airborne dust and to prolong tool and
accessorylife.
Consult your dealer for further information on suitable dust
extractionsystems.
Optional Accessories
WARNING: Since accessories, other than those offered
by DeWALT, have not been tested with this product, use
of such accessories with this tool could be hazardous.
To reduce the risk of injury, only DeWALT recommended
accessories should be used with thisproduct.
Consult your dealer for further information on the
appropriateaccessories.
D
Cleaning
WARNING: Blow dirt and dust out of the main housing
with dry air as often as dirt is seen collecting in and around
the air vents. Wear approved eye protection and approved
dust mask when performing thisprocedure.
WARNING: Never use solvents or other harsh chemicals
for cleaning the non‑metallic parts of the tool. These
chemicals may weaken the materials used in these parts.
Use a cloth dampened only with water and mild soap.
Never let any liquid get inside the tool; never immerse any
part of the tool into aliquid.
C
Lubrication
Your power tool requires no additionallubrication.
satisfactory operation depends upon proper tool care and
regularcleaning.
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.
The charger and battery pack are notserviceable.
MAINTENANCE
Your power tool has been designed to operate over a long
period of time with a minimum of maintenance. Continuous
Performing an Application (Fig. A, G)
WARNING: TO REDUCE THE RISK OF PERSONAL
INJURY, ALWAYS ensure workpiece is anchored or
clamped firmly. If drilling thin material, use a wood
“back‑up” block to prevent damage to thematerial.
WARNING: Always wait until the motor has come to
a complete standstill before changing the direction
ofrotation.
1. Choose and install the appropriate chuck, adapter, and/or
bit onto to the tool. Refer to Bit and BitHolder.
2. Using the mode selector dial
5
, selectthe mode
appropriate to desired application. Refer to
OperationModes.
3. Adjust the side handle
1
asnecessary.
4. Select the direction ofrotation using the forward/reverse
button
4
. When changing the position of the control
button, be sure the trigger isreleased.
To select forward rotation, press the for ward/re verse
control button on the right side of thetool.
To select reverse, press the forward/reverse control
button on the left side of thetool.
NOTE: The center position of the control button locks
the tool in the offposition.
5. Place the bit/chisel on the desiredlocation.
6. Depress the trigger switch
3
. The farther you depress
the trigger switch, the faster the tool will operate. For
maximum tool life, use variable speed only for starting holes
orfasteners.
7. To stop the hammer, release theswitch.
Recommendations for Tool Operation
Large (8 mm to 13mm) holes in steel can be made easier if
a pilot hole (4 mm to 5mm) is drilledfirst.
When drilling, always apply pressure in a straight line with
the bit, but do not push hard enough to stall the motor or
deflect thebit. A smooth even flow of material indicates the
proper drillingrate.
If drilling thin material or material that is prone to splinter,
use a wood “back‑up” block to prevent damage to
theworkpiece.
WARNING:
Do not use this tool to mix or pump easily combustible
or explosive fluids (benzine, alcohol,etc.).
Do not mix or stir inflammable liquids
labelledaccordingly.
NOTE: The arrow on the mode selector dial
5
must be pointing
at a mode symbol at all times. There are no operable positions
inbetween. It may be necessary to briefly run the motor after
having changed from 'hammering only' to 'rotary' modes in
order to align thegears.
