DeWalt DCMBL562N - Assembly and Adjustments; Operation

10
English
Proper Hand Position (Fig. A, E)

WARNING: To reduce the risk of serious
personal injury, ALWAYS use proper hand position
asshown.

WARNING: To reduce the risk of serious
personal injury, ALWAYS hold securely in anticipation of a
suddenreaction.

WARNING:Do not operate blower without
tube securely in place. Never reach down into housing
through tubehole.

WARNING:Always slide the lock-off switch to
the locked position and remove the battery when:
- You leave blowerunattended.
- Checking, adjusting, cleaning, or working
onblower.
OPERATION
Instructions for Use

WARNING: Always observe the safety
instructions and applicableregulations.

WARNING: To reduce the risk of serious
personal injury, turn tool off and disconnect battery
pack before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.
Inserting and Removing the Battery Pack
from the Tool (Fig. B)

WARNING: Before removing or installing
battery, make certain the speed lock lever
2
is in the off
position to prevent switchactuation.
nOTE: Make sure your battery pack
5
is fullycharged.
To Install the Battery Pack into the Tool Handle
1. Align the battery pack
5
with the rails inside the tool’s
handle (Fig. B).
Blow Tube Assembly (Fig. B)

WARNING: Do not operate blower without
tube securely in place. Never reach down into housing
through tubehole.

WARNING: Always remove the battery when
you leave blower unattended or when storing, checking,
adjusting, cleaning, or working onblower.
1. To attach the blower tube
4
to the power head, align the
peg
9
of the power head with the notch
8
of the blower
tube opening as shown in Fig. B.
2. Push the blower tube onto the power head until the tube
locks engage the blower tube and an audible click isheard.
3. Pull on the tube to ensure it is securely inplace.
4. To remove the tube, insert a screwdriver into the unlocking
hole
10
on the side of the blower tube. Depress the tab
inside and pull tubeoff.
Concentrator Assembly (Fig. C)
Use the concentrator
7
attachment to target air flow to a
tighterarea.
1. Align the concentrator
7
with the tube assembly as shown
in Fig.C.
2. Slide the concentrator
7
onto the tube
4
.
3. Push down until the tabs
11
on both sides of the
tube engage the locking holes
12
in both sides of the
concentrator
7
.
4. Pull on the concentrator 
7
to ensure it is securely inplace.
5. To remove the concentrator
7
, depress the tabs
11
and
pull the concentrator
7
away from thetube.
ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious
personal injury, turn tool off and disconnect battery
pack before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.

WARNING: Use only DeWALT battery packs
andchargers.
2. Slide it into the handle until the battery pack is firmly seated
in the tool and ensure that you hear the lock snap intoplace.
To Remove the Battery Pack from the Tool
1. Press the release button
6
and firmly pull the battery pack
out of the toolhandle.
2. Insert battery pack into the charger as described in the
charger section of thismanual.
Fuel Gauge Battery Packs (Fig. B)
Some DeWALT battery packs include a fuel gauge which
consists of three green LED lights that indicate the level of
charge remaining in the batterypack.
To actuate the fuel gauge, press and hold the fuel gauge
button
13
. A combination of the three green LED lights will
illuminate designating the level of charge left. When the level
of charge in the battery is below the usable limit, the fuel gauge
will not illuminate and the battery will need to berecharged.
nOTE: The fuel gauge is only an indication of the charge left on
the battery pack. It does not indicate tool functionality and is
subject to variation based on product components, temperature
and end-userapplication.
