DeWalt DCMWP234 - Assembly and Adjustments; Single Touch Handle Adjustments; Main Handle Height Adjustment; Storage Mode Preparation

ENGLISH
16
Grass Collection Bag (Fig.M)

DANGER: Turn unit off and remove safety key and
batterypacks.
1. Lift the rear door cover
21
, remove mulching plug
24
,
and place the grass collection bag
22
onto the mower
so the bag lugs
33
slide into the slots
39
on the inside
plastic surfaces of the handle brackets. Then lower the
rear doorcover
21
.
NOTE: If installed, remove rear side discharge chute
25
and ensure the rear door cover
21
is fullyup before
installing grass collection bag
22
.
main handle away from the handle support
2
until an
audible click is heard, indicating that it is locked into the
upper height position.
3. Ensure the main handle
4
locks intoposition
beforeproceeding.
NOTE: When the batteries
26
and safety key
6
are
inserted and the bail handle
8
is pulled, the handle
folding indicator
15
will illuminate if the single touch
handle
1
is not locked intoposition.
4. To retract the main handle
4
to the lower height
postion, press the handle release button
5
and push the
main handle
4
towards the handle support
2
until an
audible click is heard, indicating that it is locked into
the lower height position.
Storage Mode (Fig. G—L)

DANGER: MAKE CERTAIN THE SAFETY KEY IS
REMOVED TO PREVENT ACTUATION BEFORE
REMOVING OR INSTALLINGBATTERIES.

DANGER: Turn unit off and remove safety key and
batterypacks.
1. To retract the main handle
4
, press the handle release
button
5
and push the main handle
4
towards the
handle support
2
until two audible clicks are heard,
indicating that both sides of the handles are locked
intoposition. The main handle
4
must be fully seated
against the handle support.
NOTE: The main handle
4
must fully engage the handle
windows
29
. If they are not engaged as shown in Fig. G,
press the main handle
4
towards the handle support
2
until two audible clicks areheard and both sides of
handle windows
29
are closed as shown in Fig.H.
NOTE: Ensure the two storage latches
30
at the back of
the single touch handle
1
tubes pop outward as shown
in Fig. J before lowering the single touch handle
1
into
the stoarge position.
2. Fold the single touch handle
1
towards the front
wheels
32
into storage position . Listen for two audible
clicks as the two storage latches
30
slide into the
storageslots
31
as shown in Fig. K.
3. Ensure the single touch handle
1
is locked intostorage
position before proceeding.
4. The mower can be stored standing up, with the
collection bag removed, or flat on itswheels as shown
in Fig. L.
NOTE: Take care to not pinch, pull or otherwise stress
thecord
28
.
Single Touch Handle Adjustments
(Fig.D, E)
The mower is shipped in the storage position. You will need
to adjust the single touch handle
1
to the operating position
beforecontinuing.
Raise the Single Touch Handle (Fig.D)
1. To unlock the single touch handle
1
from the storage
position, squeeze the handle unlock button
3
.
NOTE: The handle unlock button
3
is located on the
back of handle support
2
.
NOTE: The main handle
4
must pop out slightly from
both sides of the single touch handle tubes before lifting
the single touch handle
1
from the storageposition as
shown in Fig. D,.
2. Raise the single touch handle
1
to the locked position.
Listen for an audible click and ensure the single touch
handle
1
is locked intoposition before proceeding.
3. Extend the main handle
4
outward until a set of audible
clicks is heard. The single touch handle
1
is now in the
operation position.
NOTE: Take care to not pinch, pull or otherwise stress
thecord
28
.
Adjusting the Main Handle Height
(Fig.F)
The main handle
4
extends to accommodate taller users.
1. To extend the main handle
4
to the lower height
position, press the handle release button
5
and pull the
main handle away from the handle support
2
until an
audible click is heard, indicating that it is locked into the
lower height position.
NOTE: The handle release button
5
is located on the
bottom of handle support
2
.
2. To extend the main handle
4
to the upper height
position, press the handle release button
5
and pull the
ASSEMBLY AND ADJUSTMENTS

DANGER: To reduce the risk of serious personal
injury, turn unit off and remove the safety key and
battery packs before making any adjustments or
removing/installing attachments or accessories.
An accidental start‑up can causeinjury.
Wall Mounting
Some DeWALT chargers are designed to be wall mountable
or to sit upright on a table or work surface.If wall mounting,
locate the charger within reach of an electrical outlet, and
away from a corner or other obstructions which may impede
air flow. Use the back of the charger as a template for the
location of the mounting screws on the wall. Mount the
charger securely using drywall screws (purchased separately)
at least 1” (25.4mm) long, with a screw head diameter of
0.28–0.35” (7–9mm), screwed into wood to an optimal
depth leaving approximately 7/32” (5.5 mm) of the screw
exposed. Align the slots on the back of the charger with the
exposed screws and fully engage them in theslots.
SAVE THESE INSTRUCTIONS FOR
FUTURE USE
