DeWalt DCPH820 User Manual

1
ENGLISH
11
12
5
13
9
8
4
10
1
7
6
3
2
15
16
14
English (original instructions)
Definitions: Safety Alert Symbols and Words
This instruction manual uses the following safety alert symbols and words to alert you to hazardous situations and your risk
of personal injury or property damage.

DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or seriousinjury.

WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or seriousinjury.

CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderateinjury.

(Used without word) Indicates a safety related message.
NOTICE: Indicates a practice not related to personal injury which, if not avoided, may result in propertydamage.

WARNING: Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
seriousinjury.
WARNING: To reduce the risk of injury, read the
instructionmanual.
If you have any questions or comments about this or
any product, call
DeWALT toll free at: (1-800-433-9258).
1
On/Off trigger
2
Lock-off lever
3
Handle
4
Auxiliary handle
5
Motor housing
6
Battery pack
7
Battery release button
8
Threaded sleeve
9
Threaded pole
10
Strap mount
11
Trimmer blade
12
Pivoting trimmer head
13
Trimmer head locking
button
14
Trimmer head handle
15
Handle assembly
16
Trimmer head assembly
Fig. A

DeWalt DCPH820 Specifications

General

Brand	DeWalt
Model	DCPH820
Category	Trimmer
Language	English
