DeWalt DCPS620 - Safety Alert Symbols and Definitions; Safety Alert Symbols and Words; Product Components; Components Identification

ENGLISH
1
English (original instructions)
Definitions: Safety Alert Symbols and Words
This instruction manual uses the following safety alert symbols and words to alert you to hazardous situations and your risk
of personal injury or property damage.

DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or seriousinjury.

WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or seriousinjury.

CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderateinjury.

(Used without word) Indicates a safety related message.
NOTICE: Indicates a practice not related to personal injury which, if not avoided, may result in propertydamage.

WARNING: Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
seriousinjury.
WARNING: To reduce the risk of injury, read the
instructionmanual.
If you have any questions or comments about this or
any
DeWALT tool, call us toll free at:
1-800-4-
DeWALT (1-800-433-9258).
COMPONENTS
1
Handle assembly
2
Center extension pole
3
Saw head assembly
4
Trigger switch
5
Lock button
6
Battery
7
Foam gripper
8
Threaded pole
9
Threaded sleeve
10
Bar clamp
11
Sprocket cover
12
Hex head screws
13
Guide bar
14
Saw chain
15
Scabbard
16
Hex wrench
17
Oil cap
18
Branch removal hook
Fig. A
4
5
6
7
8
9
18
14
15
3
2
1
11
12
10
16
17
13
