DeWalt DCR011 - Markings on Speaker; Date Code Position; Description; Intended Use

8
ENGLISH
Inserting and Removing the Battery Pack
from the Bluetooth® Speaker (Fig.B)
NOTE: Make sure your battery pack
11
is fullycharged.
To Install the Battery Pack into the Speaker
1. Align the battery pack
11
with the rails inside the speaker's
battery port
13
.
ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.

WARNING: Use only DeWALT battery packs andchargers.
USB Port (Fig.A)
The USB power output port
7
is a connection port for powering
low power devices such as mobile phones, CD and MP3 players.
It delivers up to 2.1 amp totalcurrent.
As the speaker is powered by batteries, the USB power output
port will charge a device when the user presses the power
button to turn the speakeron.
NOTE: The audio device must connect to the speaker via
Bluetooth® to use the speaker function. The USB port is only a
power port for charging the audiodevice.
Handle/Mobile Phone Cradle (Fig.C)
The speaker should be transported using the handle
8
. The
handle has a cradle which can be used to hold the mobile
phone while in use.

WARNING: A mobile phone cannot be secured in the
cradle and can fall if the speaker is moved or transported.
Be sure to remove mobile phone from the cradle before
moving or transporting thespeaker.
Mobile Phone Tray (Fig.A)
The speaker has a mobile phone tray
9
which can be used to
hold the mobile phone while inuse.

WARNING: A mobile phone cannot be secured in the tray
and can fall if the speaker is moved or transported. Be sure
to remove mobile phone from the tray before transporting
thespeaker.
Mounting the Speaker (Fig.D)
The speaker is designed to be mountable or to sit upright
on a table or work surface. If mounting, use the mounting
slots
14
found on the bottom of the speaker as a template
for the location of the screws on the wood or wall. Mount the
speaker securely using drywall screws (purchased separately)
at least 25.4mm long with a screw head diameter of 5–7mm,
screwed into wood to an optimal depth leaving approximately
5.5mm of the screw exposed. Align the slots on the back of the
speaker with the exposed screws and fully engage them in the
slots. The speaker can be mounted horizontally or vertically in
eitherdirection.
Description (Fig.A)

WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1
Power button
2
Volume buttons +/-
3
Track change buttons
4
Bluetooth® status indicator
5
Play/Pause button
6
Bluetooth® button
7
USB port
8
Handle and mobile phone cradle
9
Mobile phone tray
10
Date code
Intended Use
This DeWALT Bluetooth® speaker is designed to play/stream
audio via a wireless Bluetooth® connection to a mobile phone or
other audio device.
DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
withoutsupervision.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
Date Code Position (Fig.B)
The date code
10
, which also includes the year of manufacture,
is printed into thehousing.
Example:
2019 XX XX
Year of Manufacture
Markings on Speaker
The following pictograms are shown on the tool:
Read instruction manual beforeuse.
NOTE: The Bluetooth® word mark and logos are registered
trademarks owned by the Bluetooth®, SIG, Inc. and any use of
such marks by DeWALT is under license. Other trademarks and
trade names are those of their respectiveowners.
• Check for damage to the tool, parts or accessories which may
have occurred duringtransport.
• Take the time to thoroughly read and understand this manual
prior tooperation.
