WARNING: Ensure switch is fully OFF before installing
thebattery.
Installing/Removing Accessories (Fig.C–M,Q)
Tool-free Accessory clamp (Fig.C–E)
The DCS355, DCS356 features a quick change accessory system.
This allows for faster accessory changes without the need for
wrenches or hex keys like other oscillating toolsystems.
1. Grasp the tool and squeeze the accessory clamping lever
3
as shown in FigureC.
2. Clean any residual debris from the tool shaft and the
accessoryholder.
3. Slide the accessory between the shaft
22
and the accessory
holder making sure the accessory engages all eight pins on
the holder and is flush with the shaft. Ensure the accessory is
oriented as shown in FigureD.
4. Release the accessory clamplever.
NOTE: Some accessories, such as scrapers and blades can be
mounted at an angle if required as shown in FigureE.
Installing/Removing Sanding Sheets (Fig.F)
A diamond shaped platen uses a hook and loop adhesion
system to attach the sanding sheets. The platen allows you to
use it on large flat surfaces and tight spots orcorners.
1. Attach the sanding platen
23
as described under
Installing/RemovingAccessories.
2. Align the edges on the sanding sheet, with the edge of
the sanding platen and press the sanding sheet
24
onto
theplaten.
3. Firmly press the base with the sanding sheet attached
against a flat surface and briefly switch the tool on. This
provides for good adhesion between the platen and the
sanding sheet and also helps to prevent prematurewear.
4. When the tip of the sanding sheet becomes worn, detach
the sheet from the platen, rotate andreapply.
Attaching Accessories Using the Universal
Adapter (Fig.G)

CAUTION: To avoid injury, do not use any accessory
for an application where the adaptor may fail to hold
theaccessory.

CAUTION: Read and follow all manufacturers' safety
warnings for any accessories used with thistool.

CAUTION: To avoid injury, ensure adaptor and accessory
are securelytightened.
Non-DeWALT accessories can be attached using the
universaladaptor.
1. Place the washer
20
on thetool.
2. Place accessory
12
on towasher.
3. Tighten and secure adaptor nut
18
using hex wrench
16
.
Attaching the Cut Guide (Fig.H–M)
The depth/cut guide allows you to precisely cut material at a
specified depth and more accurately track a marked cutline.
OPERATION
Instructions for Use

WARNING: Always observe the safety instructions and
applicableregulations.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can cause injury.
1. Attach the cut guide block
6
by inserting the accessory
tabs
13
on the guide into the accessory side mount slots
5
on the main body of thetool.
NOTE: The depth/cut guide can be attached to either side
of thetool.
2. Secure the block to the main body with the supplied
screw
15
and washer
21
. Tighten with the supplied hex
wrench
16
.
Depth Guide (Fig.I, J)
This feature allows you to precisely cut material at a
specifieddepth.
1. Insert the guide arm
7
as shown in FigureI into the front
slot on the guide block
6
.
2. Adjust the length of the guide by pulling out or pushing
inward to achieve the desired cut depth as shown in
FigureJ.
3. Secure the guide in place by turning the depth/cut
adjustment knob
14
clockwise. To release the guide turn
the depth/cut adjustment knobcounterclockwise.
Cut Guide (Fig.K–M)
This feature allows you to more accurately track a marked
cutline.
1. Insert the guide arm
7
as shown in FigureK into the slots
on the left and right sides of the guide block
6
.
2. Adjust the length of the guide by pulling out or pushing
inward to achieve the desired length as shown in FigureL.
3. Secure the guide in place by turning the depth/cut
adjustment knob
14
clockwise. To release the guide turn
the depth/cut adjustment knobcounterclockwise.
NOTE: The guide arm can also be placed in the guard assembly
vertically in order to set the height off a cut. Refer to FigureM.
Attaching the Dust Extraction Adaptor (Fig.Q)
The Dust Extraction Adaptor allows you to connect the tool to
an external dust extractor, either using the AirLock™ system
(DWV9000-XJ), or a standard 35mm dust extractorfitment.
1. Attach the dust extraction adaptor
17
by inserting the
tabs
13
in to the accessory side mount slots
5
.
NOTE: The dust extraction adaptor can be attached to either
side of thetool.
2. Insert screw
15
and washer
21
into the dust extraction
adaptor
17
and tighten with the supplied hex wrench
16
.
NOTE: The fuel gauge is only an indication of the charge left on
the battery pack. It does not indicate tool functionality and is
subject to variation based on product components, temperature
and end-userapplication.
