DeWalt DCS356P2-QW Manual

ENGLISH
10
MAINTENANCE
Your power tool has been designed to operate over a long
period of time with a minimum of maintenance. Continuous
satisfactory operation depends upon proper tool care and
regularcleaning.

WARNING:To reduce the risk of serious personal injury,
turn tool off and disconnect battery pack before making
any adjustments or removing/installing attachments or
accessories. An accidental start-up can cause injury.
The charger and battery pack are notserviceable.
Proper hand position requires the tool to be held as shown in
FigureN.
Instructions for Use (Fig.N)
1. Install the batterypack.
2. To turn the tool ON, hold it as shown in FigureN and press
the variable speed trigger
1
.
NOTE: The further the trigger switch is depressed the faster the
tool will operate. If in doubt about the proper speed for your
operation, test the performance at low speed and gradually
increase until a comfortable speed isfound.
3. To turn the tool OFF, release the variable speed trigger
1
.
Lock On/Off Button (Fig.O)
The tool can be locked off by fully depressing the lock on/off
button
4
shown in FigureO.
For more comfort in extended use applications, the lock on/
off button
4
can lock the variable speed trigger
1
in the
depressedposition.
NOTE: The tool will automatically shut off after operating
for five minutes with the lock‑on button engaged. To restart
the tool, the user will have to release the trigger and repress
lock‑onbutton.
Speed Selector (Fig.A)
DCS356
Your tool is equipped with a speed selector
10
which allows
you to select one of the three speeds that limits the full speed.
Proper Hand Position (Fig. N)

WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position asshown.

WARNING: To reduce the risk of serious personal injury,
ALWAYS hold securely in anticipation of a suddenreaction.
OPERATION
Instructions for Use

WARNING: Always observe the safety instructions and
applicableregulations.

WARNING: To reduce the risk of serious personal injury,
turn tool off and disconnect battery pack before making
any adjustments or removing/installing attachments or
accessories. An accidental start-up can cause injury.
3. Secure the guide in place by turning the depth/cut
adjustment knob
14
clockwise. To release the guide turn the
depth/cut adjustment knobcounterclockwise.
NOTE: The guide arm can also be placed in the guard assembly
vertically in order to set the height off a cut. Refer to FigureM.
Attaching the Dust Extraction Adaptor (Fig.Q)
The Dust Extraction Adaptor allows you to connect the tool to
an external dust extractor, either using the AirLock™ system
(DWV9000‑XJ), or a standard 35mm dust extractorfitment.
1. Attach the dust extraction adaptor
17
by inserting the
tabs
13
into the accessory side mount slots
5
.
NOTE: The dust extraction adaptor can be attached to either
side of thetool.
2. Insert screw
15
and washer
21
into the dust extraction
adaptor
17
and tighten with the supplied hex wrench
16
.
Select the speed based on the application and control the speed
of the tool using the variable speed trigger switch
1
.
LED Worklight (Fig.P)
The LED worklight
2
will activate when the trigger is depressed.
It will automatically shut off following a short period of time
once the trigger isreleased.
Using the Dust Extraction Adaptor with the Sanding
Platen (Fig.R)
1. Attach the dust extraction adaptor
17
. Refer to Attaching
the Dust ExtractionAdaptor.
2. Attach the sanding platen
23
as described under Installing/
RemovingAccessories.
3. Attach sanding sheet as described under Installing/
Removing SandingSheets.
Using the Dust Extraction Adaptor with Plunge
Cutting Accessory (Fig.S)
1. Attach the dust extraction adaptor. Refer to Attaching the
Dust ExtractionAdaptor.
2. Push dust extraction arm
19
into the lower aperture of the
dust extraction adaptor
17
.
3. Attach plunge cutting blade as described under Installing/
RemovingAccessories.
4. Adjust the dust extraction arm
19
for bestresults.
Helpful Hints
• Always ensure the workpiece is firmly held or clamped to
prevent movement. Any movement of the material may affect
the quality of the cutting or sandingfinish.
• Do not start sanding without having the sandpaper attached
to sandingplaten.
• Use coarse grit paper to sand rough surfaces, medium grit
for smooth surfaces and fine grit for the finishing surfaces. If
necessary, first make a test run on scrapmaterial.
• Excessive force will reduce the working efficiency and cause
motor overload. Replacing the accessory regularly will maintain
optimum workingefficiency.
• Do not allow the sandpaper to wear away, it will damage the
sandingpad.
• If the tool overheats, especially when used at low speed, set
the speed to maximum and run it with no load for 2–3 minutes
to cool the motor. Avoid prolonged usage at very low speeds.
Always keep the bladesharp.
Lubrication
Your power tool requires no additionallubrication.
Cleaning

WARNING: Electrical shock and mechanical hazard.
Disconnect the electrical appliance from the power source
beforecleaning.

WARNING: Ensure switch is fully OFF before installing
thebattery.
