DeWalt DCS574 User Manual

ENGLISH
9
OPERATION

WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/installing
attachments or accessories. An accidental start-up can
causeinjury.
Installing and Removing the Battery Pack (Fig. D)
NOTE: For best results, make sure your battery pack is
fullycharged.
To install the battery pack
3
into the tool handle, align the
battery pack with the rails inside the tool’s handle and slide
it into the handle until the battery pack is firmly seated in
the tool and ensure that it does notdisengage.
To remove the battery pack from the tool, press the release
button
13
and firmly pull the battery pack out of the tool
handle. Insert it into the charger.
Worklight (Fig. A)

CAUTION: Do not stare into worklight. Serious eye
injury couldresult.
There is a worklight
15
located just below the blade lock
button
11
. The worklight is activated when the trigger
switch is depressed, and will automatically turn off 20
seconds after the trigger switch is released. If the trigger
switch remains depressed, the worklight will remainon.
NOTE: The worklight is for lighting the immediate work
surface and is not intended to be used as aflashlight.
Trigger Switch (Fig. E)

WARNING: This tool has no provision to lock the trigger
switch in the ON position and should never be locked ON by
any othermeans.
Release the trigger switch lock-off button
1
by pressing
the button as shown. Pull the trigger switch
2
to turn the
motor on. Releasing the trigger switch turns the motoroff.
Changing Blades (Fig. F–H)

WARNING: Remove battery from tool before
changingblades.
To Install the Blade (Fig.F–H)
1. Retract the lower blade guard
7
using the lower blade
retracting lever
6
and place the blade on the saw spindle
against the inner clamp washer, making sure that the blade
will rotate in the proper direction (the direction of the
rotation arrow on the saw blade and the teeth must point
in the same direction as the direction of rotation arrow on
the lower blade guard). Do not assume that the printing on
the blade will always be facing you when properly installed.
When retracting the lower blade guard to install the blade,
check the condition and operation of the lower blade guard
to assure that it is working properly. Make sure it moves
freely and does not touch the blade or any other part, in all
angles and depths ofcut.
2. Place outer clamp washer
17
on saw spindle with
the large flat surface against the blade with beveled side
facingout.
3. Thread blade clamping screw
8
into saw spindle by
hand (screw has right-hand threads and must be turned
clockwise totighten).
4. Depress the blade lock button
11
while turning the saw
spindle with the blade wrench (
14
, Fig. G) until the blade
lock engages and the blade stopsrotating.
5. Tighten the blade clamping screw firmly with the
bladewrench.
NOTE: Never engage the blade lock while saw is running,
or engage in an effort to stop the tool. Never turn the saw
on while the blade lock is engaged. Serious damage to your
saw willresult.
To Replace the Blade (Fig.F, G)
1. To loosen the blade clamping screw
8
, depress the
blade lock button
11
and turn the saw spindle with the
blade wrench
14
until the blade lock engages and the
blade stops rotating. With the blade lock engaged, turn
the blade clamping screw counterclockwise with the blade
wrench (screw has right-hand threads and must be turned
counterclockwise toloosen).
2. Remove the blade clamping screw
8
and outer clamp
washer
17
only. Remove oldblade.
3. Clean any sawdust that may have accumulated in the
guard or clamp washer area and check the condition and
operation of the lower blade guard as previously outlined.
Do not lubricate thisarea.
4. Select the proper blade for the application (see Blades).
Always use blades that are the correct size (diameter)
with the proper size and shape center hole for mounting
on the saw spindle. Always assure that the maximum
recommended speed (rpm) on the saw blade meets or
exceeds the speed (rpm) of thesaw.
5. Follow steps 2 through 5 under To Install the
Blade, making sure that the blade will rotate in the
properdirection.
Lower Blade Guard

WARNING: The lower blade guard is a safety feature
which reduces the risk of serious personal injury.
Never use the saw if the lower blade guard is missing,
damaged, misassembled or not working properly. Do
not rely on the lower blade guard to protect you under
all circumstances. Your safety depends on following
all warnings and precautions as well as proper
operation of the saw. Check lower blade guard for
proper closing before each use as outlined in Further
Safety Instructions for All Saws. If the lower blade
guard is missing or not working properly, have the saw
serviced before using. To assure product safety and
reliability, repair, maintenance and adjustment should
be performed by an authorized service center or other
qualified service organization, always using identical
replacementparts.
Blades

WARNING: To minimize the risk of eye injury, always use
eye protection. Carbide is a hard but brittle material. Foreign
objects in the workpiece such as wire or nails can cause tips
to crack or break. Only operate saw when proper saw blade
guard is in place. Mount blade securely in proper rotation
direction before using, and always use a clean, sharp blade.

WARNING: Do not cut metal, plastic, concrete, masonry
or fiber cement materials with thissaw.
Do not use abrasive wheels or blades. A dull blade will
cause slow inefficient cutting, overload on the saw motor,
excessive splintering, and could increase the possibility of
kickback. Please refer to the table below to determine the
correct size replacement blade for your modelsaw.
