DeWalt DCS781 User Manual

7
ENGLISH
English (original instructions)
MITRE SAW
DCS781
You have chosen a DeWALT tool. Years of experience, thorough product development and
innovation make DeWALT one of the most reliable partners for professional power toolusers.
Technical Data
DCS781
Voltage V
DC
54
Type 20
Battery type Li‑Ion
Blade diameter
mm 305
Blade bore
mm 30
Blade body thickness
mm 1.6
Max. kerf thickness
mm 2.2
Max. blade speed
min
‑1
3800
Max. cross‑cut capacity 90°
mm 310
Max. mitre capacity 45°
mm 219
Max. depth of cut 90°
mm 112
Max. depth of bevel cross‑cut 45°
mm 50
Mitre (max. positions)
left 50°
right 60°
Bevel (max. positions)
left 49°
right 49°
0 ° mitre
Resulting width at baseboard max. height 165mm
mm 19
Resulting width at max height 112 mm
mm 278
Resulting height at max width 310 mm
mm 90
45 ° mitre left
Resulting width at max. height 112mm
mm 197
Resulting height at max. width 219mm
mm 90
45 ° mitre right
Resulting width at max. height 112mm
mm 197
Resulting height at max. width 219mm
mm 90
45 ° bevel left
Resulting width at max. height 60 mm
mm 278
Resulting height at max. width 310 mm
mm 54
45 ° bevel right
Resulting width at max. height 50mm
mm 296
Resulting height at max. width 310 mm
mm 40
Automatic blade brake time
s <5
Wireless tool control transmitter
Frequency band
Max. power (EIRP)
MHz
mW
433
0.03
Weight (without battery pack) kg 23.2
Noise values and/or vibration values (triax vector sum) according to EN62841‑3‑9:
L
PA
(emission sound pressure level) dB(A) 94.4
L
WA
(sound power level) dB(A) 106.4
K (uncertainty for the given sound level) dB(A) 2.5
The vibration and/or noise emission level given in this information sheet has been measured
in accordance with a standardised test given in EN62841 and may be used to compare one
tool with another. It may be used for a preliminary assessment ofexposure.

WARNING: The declared vibration and/or noise emission level represents the main
applications of the tool. However if the tool is used for different applications, with different
accessories or poorly maintained, the vibration and/or noise emission may differ. This
may significantly increase the exposure level over the total workingperiod.
An estimation of the level of exposure to vibration and/or noise should also take
into account the times when the tool is switched off or when it is running but not
actually doing the job. This may significantly reduce the exposure level over the total
workingperiod.
Identify additional safety measures to protect the operator from the effects of vibration
and/or noise such as: maintain the tool and the accessories, keep the hands warm
(relevant for vibration), organisation of workpatterns.
EC‑Declaration of Conformity
Machinery Directive and Radio Equipment Directive
Mitre Saw
DCS781
DeWALT declares that these products described under Technical Data are in compliance with:
2006/42/EC, EN62841‑1:2015 +AC:2015; EN62841‑3‑9:2015 +AC:2016 +A11:2017.
These products also comply with Directive, 2014/53/EU; 2014/30/EU and 2011/65/EU. For
more information, please contact DeWALT at the following address or refer to the back of
themanual.
The undersigned is responsible for compilation of the technical file and makes this declaration
on behalf ofDeWALT.
Markus Rompel
Vice President of Engineering, PTE‑Europe
DeWALT, Richard‑Klinger‑Straße 11,
65510, Idstein, Germany
29.04.2022
DECLARATION OF CONFORMITY
THE SUPPLY OF MACHINERY (SAFETY) REGULATIONS 2008 AND
RADIO EQUIPMENT REGULATION 2017
Mitre Saw
DCS781
DeWALT declares that these products described under “technical data” are in compliance with:
The Supply of Machinery (Safety) Regulations, 2008, S.I. 2008/1597 (as amended),
EN62841‑1:2015 +AC:2015; EN62841‑3‑9:2015 +AC:2016 +A11:2017.
These products conform to the following UK Regulations
Radio Equipment Regulation 2017, S.I.2017/1206 (as amended)
Electromagnetic Compatibility Regulations, 2016, S.I.2016/1091 (asamended).
The Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic
Equipment Regulations 2012, S.I. 2012/3032 (as amended).
For more information, please contact DeWALT at the following address or refer to the back of
the manual.
The undersigned is responsible for compilation of the technical file and makes this declaration
on behalf of DeWALT.
Karl Evans
Vice President Professional Power Tools EANZ GTS
DeWALT UK, 270Bath Road, Slough
SL1 4DX
England
29.04.2022
WARNING: To reduce the risk of injury, read the instructionmanual.
Definitions: Safety Guidelines
The definitions below describe the level of severity for each signal word. Please read the
manual and pay attention to thesesymbols.

DANGER: Indicates an imminently hazardous situation which, if not avoided, will result
in death or seriousinjury.

WARNING: Indicates a potentially hazardous situation which, if not avoided, could result
in death or seriousinjury.

CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result
in minor or moderateinjury.
NOTICE: Indicates a practice not related to personal injury which, if not avoided, may
result in propertydamage.

Denotes risk of electricshock.

Denotes risk offire.
