Service and Repairs
Note: Disassembling the laser level will void all warranties on the product.
To assure product SAFETY and RELIABILITY, repairs, maintenance and adjustment should be performed by authorized service
centers. Service or maintenance performed by unqualied personnel may result in a risk of injury. To locate your nearest D
EWALT
service center, go to http://www.DEWALT.com.
Specications
DW08802 DW08802CG
Light Source Laser diode
Laser Wavelength 630 – 680 nm visible 510 – 530 nm visible
Laser Power ≤1.5 mW CLASS 2 LASER PRODUCT
Working Range 33′ (10m) 50′ (15m)
Accuracy ±0.25” @ 33′ (±6 mm @ 10m)
Power Source 2 AA (1.5V) size batteries (3V DC)
Operating Temperature 14°F to 104°F (-10°C to 40°C)
Storage Temperature -5°F to 140°F (-20°C to 60°C)
Environmental Water & Dust Resistant to IP54
