DeWalt DW089 Original Instruction

ENGLISH
75
 • Ifthedetectorisstillnotmakinganysound,takeittoaDEWALT
service centre.
THE DETECTOR DOES NOT RESPOND TO THE BEAM FROM ANOTHER LASER
UNIT
 • TheDeWALT Digital Laser Detector has been designed to work
only with the DW088 and the DW089 and certain other compatible
line lasers.
THE DETECTOR GIVES OFF A TONE BUT THE LCD DISPLAY WINDOW DOES NOT
FUNCTION
 • Ifthedetectorisverycold,allowittowarmupinaheatedarea.
 • IftheLCDdisplaywindowisstillnotfunctioning,takethedetector
to a DeWALT service centre.
BRIGHT LIGHT SHINING ON DETECTOR CAUSES CONTINUOUS “ON-GRADE”
SIGNAL
 • In the presence of very intense ambient light, the detector may give
a false or erratic indication of level.
 • Reposition the detector out of the intense light or shade the sensor
window (u) to resume normal operation.
Optional Accessories
Using the Laser with Accessories (fig. 1 inset)
The laser is equipped with a 1/4" x 20 female thread (i) on the bottom
of the unit. This thread is to accommodate current or future DeWALT
accessories. Only use DeWALT accessories specified for use with this
product. Follow the directions included with the accessory.
Consult your dealer for further information on the appropriate
accessories.
These are:
  •DE0734DeWALT grade rod
  •DE0737DeWALT grade rod
  •DE0881DeWALT tripod

DeWalt DW089 Specifications

General

Range with Detector	165 feet
Self-Leveling Range	+/- 4 degrees
Power Source	4 AA batteries
Mounting Thread	1/4 inch and 5/8 inch
Number of Beams	3
Battery Life	30 hours
Warranty	3 years limited
Accuracy	±1/8 inch at 30 feet
Laser Class	Class 2
Direction	Horizontal and Vertical
Durability	IP54 water/debris resistance
