15
ENGLISH
OPTICAL LEVEL DW096
Congratulations!
You have chosen a DEWALT product. Years of
experience, thorough product development and
innovation make D
EWALT one of the most reliable
partners for professional users.
Technical data
DW096
Type 1
Objective mm 38
Magnifi cation 26 x
Accuracy (1 km double-run levelling) mm 2
Viewing angle 1° 20'
Min. focus m 0.5
Threaded pin M16 x 11
Weight kg 1.85
Defi nitions: Safety Guidelines
The definitions below describe the level of severity for
each signal word. Please read the manual and pay
attention to these symbols.
DANGER: Indicates an imminently
hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING: Indicates a potentially
hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION: Indicates a potentially
hazardous situation which, if not avoided,
may result in minor or moderate
injury.
NOTICE: Indicates a practice not
related to personal injury which, if
not avoided, may result in property
damage.
Denotes risk of electric shock.
Denotes risk of fire.
WARNING: To reduce the risk of injury,
read the instruction manual.
Safety instructions for optical instruments
• Do not use the attachment for any purpose other
than measuring heights, distances and angles.
• Do not look at strong light sources or the sun
with optical instruments.
• Do not use optical instruments to view laser beams.
• Avoid using the attachment while standing on
potentially unstable objects such as scaffolding
and stairs.
Markings on Tool
The following pictograms are shown on the tool:
Read instruction manual before use.
DATE CODE POSITION
The Date Code, which also includes the year of
manufacture, is printed into the housing.
Example:
2010 XX XX
Year of Manufacture
Package contents
The package contains:
1 Optical level
1 Tripod
1 Grade rod
1 Kitbox
1 Plumb bob
1 Instruction manual
• Take the time to thoroughly read and understand
this manual prior to operation.
