ENGLISH
11
• Place the grinding wheel on the backing flange.
• Screw the threaded flange (14) onto the
spindle (12).
• Press the spindle lock (5) and rotate the grinding
wheel until it locks in position.
• Tighten the threaded flange using the two-pin
spanner (13) supplied.
• Release the spindle lock.
• To remove the grinding wheel, loosen the
threaded flange using the two-pin spanner
(while the spindle lock is engaged).
Fitting and Removing a
Backing Pad/Sanding Sheet
(fi g. D, E)
• Place the tool on a table, guard up.
• Remove the backing flange (11).
• Place the rubber backing pad correctly onto the
spindle (12).
• Place the sanding sheet on the rubber backing
pad.
• Screw the threaded clamp nut (14) onto the
spindle. The ring on the threaded clamp nut (14)
must face towards the rubber backing pad.
• Press the spindle lock button (5) and rotate the
spindle (12) until it locks in position.
• Tighten the threaded clamp nut (14) with the
two-pin spanner.
• Release the spindle lock
• To remove the rubber backing pad, loosen
the threaded clamp nut (14) wih the two-pin
spanner.
Prior to Operation
• Install the appropriate guard and disk or wheel.
Do not use excessively worn disks or wheels.
• Do not use a damaged accessory. Before each
use inspect the accessory such as abrasive
wheels for chips and cracks, backing pad for
cracks, tear or excess wear, wire brush for loose
or cracked wires. If power tool or accessory
is dropped, inspect for damage or install an
undamaged accessory. After inspecting and
installing an accessory, position yourself and
bystanders away from the plane of the rotating
accessory and run the power tool at maximum
no-load speed for one minute. Damaged
accessories will normally break apart during this
test time.
• Be sure the inner and outer flange are mounted
correctly. Follow the instructions given in the
Grinding and Cutting Accessory Chart.
• Make sure the disk or wheel rotates in the
direction of the arrows on the accessory and
the tool.
• Do not use cutting-off wheels for side grinding.
• Ensure that sparks resulting from use do not
create hazard e.g. do not hit persons, or ignite
flammable substances.
OPERATION
Instructions for Use
WARNING: Always observe the safety
instructions and applicable regulations.
WARNING: To reduce the risk
of serious personal injury, turn
tool off and disconnect tool from
power source before making any
adjustments or removing/installing
attachments or accessories. Before
reconnecting the tool, depress and
release the trigger switch to ensure that
the tool is off.
WARNING:
• Ensure all materials to be ground or
cut are secured in place.
• Use clamps or a vice to hold
and support the workpiece to a
stable platform. It is important to
clamp and support the workpiece
securely to prevent the movement
of the workpiece and loss of control.
Movement of the workpiece or loss
of control may create a hazard and
cause personal injury.
• Secure the workpiece. A workpiece
clamped with clamping devices or in
a vice is held more secure than by
hand.
• Support panels or any oversized
workpiece to minimize the risk of
wheel pinching and kickback. Large
workpieces tend to sag under their
own weight. Supports must be
placed under the workpiece near the
line of cut and near the edge of the
workpiece on both sides of the wheel.
• Always wear regular working gloves
while operating this tool.
