DeWalt DWCS600 - Saw Chain and Guide Bar Oiling; Auto Oiling System; Filling the Oil Reservoir; Transporting the Chainsaw

9
ENGLISH
Operating the Chainsaw (Fig.A)

WARNING: Read and understand all instructions.
Failure to follow all instructions listed below may result
in electric shock, fire and/or serious personalinjury.
• Guard Against Kickback which can result in severe
injury or death. See Important Safety Instructions
Guard Against Kickback, to avoid the risk
ofkickback.
• Do not overreach. Do not cut above chest height.
Make sure your footing is firm. Keep feet apart.
Divide your weight evenly on bothfeet.
• Use a firm grip with your left hand on the front
handle
11
and your right hand on the rear
handle
10
so that your body is to the left of the
guidebar.
• Do not hold chainsaw by front hand guard
3
.
Keep elbow of left arm locked so that left arm is
straight to withstand akickback.

WARNING: Never use a cross‑handed grip (left hand
on the rear handle and right hand on the fronthandle).

WARNING: Never allow any part of your body to
be in line with the guide bar(6when operating the
chainsaw.
• Never operate while in a tree, in any awkward
position or on a ladder or other unstable surface.
You may lose control of saw causing severeinjury.
• Keep the chainsaw running at full speed the entire
time you arecutting.
Attaching Extension Cord (Fig. G)
An extension cord retainer
13
is built into the main handle
that prevents the cord from comingunplugged.
• To use this feature, simply double the extension cord
about 8" (203mm) from the end, and insert it into the
slot
20
in the end of the handle area as shown in Fig.G.
• Hook the loop formed by doubling the cord over the
extension cord retainer
13
. Gently tug on the cord to
insure that it is firmly retained in the mainhandle.
• Plug the receptacle end of the extension cord into the
power cord plug
12
in the mainhandle.
Proper hand position requires the left hand on the front
handle
11
, with the right hand on the rear handle
10
.
Proper Hand Position (Fig. F)

WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position asshown.

WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
suddenreaction.
OPERATION

WARNING: To reduce the risk of serious personal
injury, turn unit off and disconnect it from
power source before making any adjustments or
removing/installing attachments or accessories.
An accidental start‑up can causeinjury.
Transporting Chain Saw (Fig.A)
• Always disconnect from the power source from the tool
and cover the guide bar
6
with the scabbard
9
when
transporting thesaw.
Saw Chain and Guide Bar Oiling (Fig.A)
Auto Oiling System
This chainsaw is equipped with an auto oiling system that
keeps the saw chain and guide bar constantly lubricated.
The oil level indicator
15
shows the level of the oil in the
chainsaw. If the oil level is less than a quarter full, disconnect
the tool from the power source and refill with the correct
type of oil. Always empty oil tank when finishedcutting.
NOTE: Use a high quality bar and chain oil for proper saw
chain and bar lubrication. As a temporary substitute, a non-
detergent SAE30 weight motor oil can be used. The use of
a vegetable based bar and chain oil is recommended when
pruning trees. Mineral oil is not recommended because it
may harm trees. Never use waste oil or very thick oil. These
may damage yourchainsaw.
Filling the Oil Reservoir
1. Unscrew counterclockwise and then remove the oil
cap
14
. Fill the reservoir with the recommended bar and
chain oil until the oil level has reached the top of the oil
level indicator
15
.
2. Refit the oil cap and tightenclockwise.
3. Periodically switch the chainsaw off and check the oil
level indicator to ensure the bar and chain are being
properlyoiled.
Replacement chain and bar are available from your
nearest authorized servicecenter.
• This chain saw requires replacement 18 inch (450mm) chain
DWO1DT618. Replacement 18 inch (450mm) barDWZCSB18.

WARNING: Sharp moving chain. To prevent accidental
operation, ensure the tool is unplugged before
performing the following operations. Failure to do this
could result in serious personalinjury.
1. To remove the saw chain
5
, place the saw on a flat,
firmsurface.
2. Remove sprocket cover
6
as described in Installing the
Guide Bar and Saw Chainsection.
3. Rotate the chain tension screw
8
in the front of the
housing using the flat screwdriver end of the wrench.
Turning the screw counterclockwise allows the guide
bar
4
to recede and reduces the tension on the chain so
that it may beremoved.
4. Wearing protective gloves, grasp the saw chain and lift
the worn saw chain out of the groove in the guidebar.
5. Flip guide bar over every time you replace the chain to
ensure evenwear.
6. Place the new chain in the slot of the guide bar, making
sure the saw teeth are facing the correct direction by
matching the arrow and graphic of the saw chain on the
sprocket cover
6
shown in Fig.E.
7. Follow instructions for Installing the Guide Bar and
SawChain.
