EC‑Declaration of Conformity
Machinery Directive
o
Variable Speed Percussion Drill
DWD024, DWD024S, DWD025
DeWALT declares that these products described under
Technical Data are in compliance with:
2006/42/eC, eN 62841-1:2015+A11:2022,
eN 62841-2-1:2018+A11:2019+A1:2022+A12:2022.
the tool and the accessories, keep the hands warm
(relevant for vibration), organisation of workpatterns.
The vibration and/or noise emission level given in this information
sheet has been measured in accordance with a standardised test
given in EN62841 and may be used to compare one tool with
another. It may be used for a preliminary assessment ofexposure.

WARNING: The declared vibration and/or noise emission
level represents the main applications of the tool. However
if the tool is used for different applications, with different
accessories or poorly maintained, the vibration and/or
noise emission may differ. This may significantly increase
the exposure level over the total workingperiod.
An estimation of the level of exposure to vibration and/or
noise should also take into account the times when the tool
is switched off or when it is running but not actually doing
the job. This may significantly reduce the exposure level
over the total workingperiod.
Identify additional safety measures to protect the operator
from the effects of vibration and/or noise such as: maintain
DWD024
QS/GB/LX
DWD024S
QS
DWD024S
XE
DWD025
XE
Voltage V
AC
230/220–240 230/220 230 230
UK & Ireland V
AC
230/115 230 – –
Type 1 1 1 1
Power input W 701 701 650 750
No load speed /min 0–2800 0–2800 0–2800 0–2800
No load impact /min 0–47600 0–47600 0–47600 0–47600
Maximum drilling range: steel/wood/concrete mm 13/25/16 13/25/16 13/25/16 13/25/16
Torque Nm 5.2 5.2 5.2 5.2
Chuck spindle, thread size UNF 1/2" x 20 1/2" x 20 1/2" x 20 1/2" x 20
Collar diameter mm 43 43 43 43
Maximum chuck capacity mm 13 13 13 13
Weight kg 1.6 1.6 1.6 1.6
Noise values and/or vibration values (triax vector sum) according to EN62841-2-1:
L
PA
(emission sound pressure level) dB(A) 97 97 97 97
L
WA
(sound power level) dB(A) 105 105 105 105
K (uncertainty for the given sound level) dB(A) 5 5 5 5
Impact drilling
Vibration emission value a
h,ID
= m/s
2
26 26 26 26
Uncertainty K = m/s
2
2.3 2.3 2.3 2.3
Drilling into metal
Vibration emission value a
h,M
= m/s
2
4.6 4.6 4.6 4.6
Uncertainty K = m/s
2
1.5 1.5 1.5 1.5
Congratulations!
You have chosen a DeWALT tool. Years of experience, thorough product development and innovation make DeWALT one of the
most reliable partners for professional power toolusers.
Technical Data
English (original instructions)
VARIABLE SPEED PERCUSSION DRILL
DWD024, DWD024S, DWD025

DeWalt DWD024 Specifications

General

Chuck type	Key
Adjustable speed	Yes
Idle speed (max)	2800 RPM
Impact rate (high speed)	47600 bpm
Drilling diameter in wood (max)	25 mm
Drilling diameter in steel (max)	10 mm
Drilling diameter in concrete (max)	16 mm
Input power	650 W
Power source	AC
Product color	Black, Silver, Yellow

Weight and Dimensions

Weight	16500 g
