DeWalt DWOAS5BC User Manual

9
ENGLISH
Three Year Limited Warranty
DeWALT
will repair or replace, without charge, any defects
due to faulty materials or workmanship for three years
from the date of purchase (two years for batteries). This
warranty does not cover part failure due to normal wear
or tool abuse. For further detail of warranty coverage and
warranty repair information, visit www.dewalt.com or call
1‑800‑4‑
DeWALT
(1-800-433-9258). This warranty does
not apply to accessories or damage caused where repairs
have been made or attempted by others. THIS LIMITED
WARRANTY IS GIVEN IN LIEU OF ALL OTHERS, INCLUDING
THE IMPLIED WARRANTY OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, AND EXCLUDES ALL
INCIDENTAL OR CONSEQUENTIAL DAMAGES. Some states do
not allow limitations on how long an implied warranty lasts
or the exclusion or limitation of incidental or consequential
damages, so these limitations may not apply to you. This
warranty gives you specific legal rights and you may have
other rights which vary in certain states orprovinces.
In addition to the warranty
DeWALT
tools are covered byour:
1 YEAR FREE SERVICE
DeWALT
will maintain the tool and replace worn parts caused
by normal use, for free, any time during the first two years
afterpurchase.
2YEARS FREE SERVICE ON D
e
WALT BATTERYPACKS
DC9071, DC9091, DC9096, DC9182, DC9280, DC9360,
DCB120, DCB122, DCB124, DCB127, DCB201, DCB203BT,
DCB207,DCB361
3YEARS FREE SERVICE ON D
e
WALT BATTERYPACKS
DCB200, DCB203, DCB204, DCB204BT, DCB205, DCB205BT,
DCB206, DCB208, DCB230, DCB240, DCB606, DCB609,
DCB612, DCB615
NOTE: Battery warranty voided if the battery pack is
tampered with in any way.
DeWALT
is not responsible for any
injury caused by tampering and may prosecute warranty
fraud to the fullest extent permitted bylaw.
90DAY MONEY BACK GUARANTEE
If you are not completely satisfied with the performance of
your
DeWALT
Power Tool or Nailer for any reason, you can
return it within 90days from the date of purchase with a
receipt for a full refund – no questionsasked.
LATIN AMERICA: This warranty does not apply to products
sold in Latin America. For products sold in Latin America,
see country specific warranty information contained in
the packaging, call the local company or see website for
warrantyinformation.
FREE WARNING LABEL REPLACEMENT: If your warning
labels become illegible or are missing, call 1‑800‑4‑
DeWALT
(1-800-433-9258) for a freereplacement.
Register Online
Thank you for your purchase. Register your product nowfor:
• WARRANTY SERVICE: Registering your product will
help you obtain more efficient warranty service in case
there is a problem with yourproduct.
• CONFIRMATION OF OWNERSHIP: In case of an
insurance loss, such as fire, flood or theft, your registration
of ownership will serve as your proof ofpurchase.
• FOR YOUR SAFETY: Registering your product will
allow us to contact you in the unlikely event a safety
notification is required under the Federal Consumer
SafetyAct.
• Register online at www.dewalt.com
Repairs
The charger and battery pack are notserviceable. There are
no serviceable parts inside the charger or batterypack.

WARNING: To assure product SAFETY and RELIABILITY,
repairs, maintenance and adjustment (including brush
inspection and replacement, when applicable) should
be performed by a
DeWALT
factory service center or a
DeWALT
authorized service center. Always use identical
replacementparts.
2. While holding the screwdriver, remove the flange nut 
21
by turning it counterclockwise with a 13mm wrench
(not supplied) as shown in Fig.D.
3. Remove the blade spacer 
22
and the blade 
4
as
shown in Fig. D. Examine all pieces for damage and
replace ifnecessary.
Installing the New Cutting Blade
1. Install new blade
4
on shoulder of the blade cutter shaft
bushing
18
as shown in Fig.D.
2. Align the shaft bushing hole
19
with the locking rod
slot
20
and insert a screwdriver into the bushinghole.
3. Hold the screwdriver inposition.
4. Install the blade spacer 
22
on the blade so that the
wide flat side faces theblade.
5. Install flange nut
21
with the flange against the blade
spacer
22
and securely tighten with a13mm wrench
(notsupplied).
6. Tighten nut counterclockwise against the blade while
holding the locking rod:
‑ If using a torque wrench and an 13mm socket
tighten to: 325‑335 in lb, 27‑ 28ft. lb, 37‑ 38Nm.
‑ Without a torque wrench, use a 13mm closed‑end
or socket wrench, turning the nut until the blade
retainer is snug against the shaft bushing. Ensure that
the blade is installed correctly, then rotate the nut an
additional 1/4 to 1/2 turncounterclockwise.
7. Remove the screwdriver from the locking rod slot
20
.

DeWalt DWOAS5BC Specifications

General

Brand	DeWalt
Model	DWOAS5BC
Category	Brush Cutter
Language	English
