ENGLISH
Description (Fig.A)

WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1
Front speakers (2x)
2
Carrying handle
3
Control panel
4
LCD display screen
5
Stacking latches (2x)
6
Compartment latch
7
Compartment cover
8
Power‑in port (24 VDC)
9
Rear loudspeakers (2x)
10
USB power/charging port
11
Auxiliary jack (3.5 mm)
12
AC/DC power adaptor
compartment
13
Compartment cover
14
Battery pack receptacle
15
Storage space
16
Back button
17
Left button
18
Right button
19
Home button
20
Touch buttons (×6)
• To open the compartment, release the cover locking latch
and openit.
• To reach the battery pack receptacle, open the
compartment topcover.
• To close the compartment, push the cover down until it is
locked inplace.
NOTE: When correctly closed, the compartment protects its
contents from dust, debris and lightrain.
Intended Use
The
DeWALT
® TSTAK™ CONNECT RADIO includes a built‑in
FM and DAB radio, Bluetooth support, 3.5mm AUX connector
port to play audio/music from an external appliance, and an
intuitive application for remote controlling the system via a
Bluetooth‑enabled smartphone or tablet. The system includes
charging capabilities for
DeWALT
® slide pack batteries. The
TSTAK™ CONNECT RADIO will charge most
DeWALT
® Li‑ion
batteries. Batteries soldseparately.
Do not use under wet conditions or in the presence of
flammable liquids orgases.
Do not let children come into contact with the tool. Supervision
is required when inexperienced operators use thistool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
withoutsupervision.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
Direct current
Class II Construction (double insulated)
CE Mark
Safety alert symbol
Markings on Tool
The following pictograms are shown on the tool:
V Volts
A Amperes
W Watts
h Hours
Package Contents
The package contains:
1 Radio/Charger
1 Li‑Ion battery pack (C1, D1, L1, M1, P1, S1, T1, X1, Y1 models)
2 Li‑Ion battery packs (C2, D2, L2, M2, P2, S2, T2, X2, Y2 models)
3 Li‑Ion battery packs (C3, D3, L3, M3, P3, S3, T3, X3, Y3 models)
1 Instruction manual
NOTE: Battery packs, chargers and kitboxes are not included
with N models. Battery packs and chargers are not included with
NT models. Bmodels include Bluetooth® batterypacks.
NOTE: The Bluetooth® word mark and logos are registered
trademarks owned by the Bluetooth®, SIG, Inc. and any use of
such marks by
DeWALT
is under license. Other trademarks and
trade names are those of their respectiveowners.
• Check for damage to the tool, parts or accessories which may
have occurred duringtransport.
• Take the time to thoroughly read and understand this manual
prior tooperation.
Do not expose towater.
Have defective cords replacedimmediately.
Charge only between 4˚C and 40˚C.
Only for indooruse.
Discard the battery pack with due care for
theenvironment.
Charge
DeWALT
battery packs only with designated
DeWALT
chargers. Charging battery packs other
than the designated
DeWALT
batteries with a
DeWALT
charger may make them burst or lead to
other dangeroussituations.
Do not incinerate the batterypack.
USE (without transport cap). Example: Wh rating
indicates 108Wh (1 battery with 108Wh).
TRANSPORT (with built‑in transport cap). Example:
Wh rating indicates 3x 36Wh (3batteries of 36Wh).
