DeWalt DXCM024-0434 - Specifications

2
English
DXCM024-0434 Air Hose Reel
A. Air line outlet (to air tool/accessory)
B. Hose bend restrictor
C. Ball stop
D. Hose guide
E. Hose reel enclosure
F. Mounting bracket
G. Air hose
H. Air line inlet
I. Lead-in air hose (attached to hose reel)
J. Hose reel mounting pin
Specifications
MODEL DXCM024-0434
NET WEIGHT 12.3 lbs. (5,6 kg)
AIR INLET SIZE 1/4" NPT (6,3 mm)
(female/hembra/femelle)
HOSE TYPE Hybrid polymer
AIR HOSE SIZE 3/8" (9,5 mm)
MAX. AIR PRESSURE 300 PSI (2,068 kPa)
AIR HOSE LENGTH 50' (15,2 m)
A
I
B
C
D
G
H
F
J
E
Figure 1
