DeWalt DXST4500 - Parts List

6
DXST4500
PARTS LIST
No. Description
1 Vertical Beam
2 Pre-Bolted Vertical Assembly
3 Vertical Assembly Bolt
4 Carriage Bolt
5 Crossbeam
6 Shelf Support Strap
7 Safety Strap With Weld Nut
8 Safety Strap Bolt
No. Description
9 Laminate Deck
10 10 mm Nut
11 Locking Shelf Pin
12 Stacking Plate
13 10 mm Wrench
14 4 mm Hex Key
15 4 mm Hex Bit
16 Wall Mount Bracket Assembly
4
3
BEFORE YOU BEGIN:
• Read all instructions thoroughly.
• Remove all components from the box, and lay them on the floor
in an orderly fashion.
• Keep this information for further reference.
• If you are not stacking a second rack at this time, then please
store the Stacking Plates for potential future use as they
will be needed.
FPO
6
7
11
12
13
14
15
16
2
2
4
2
6
9
6
12
3
2
16
2
1
1
1
1
Qty.
Qty.
10
8
