18
English
1
Top handle/cord wrap
2
Power cord
3
3
On/off control switch
4
4
Vacuum head
5
4
5
5
Lid latches
6
Dust tank
7
9
7
Hose
8
Casters
9
Clean connect lter
TM
10
10
10
7 13
10
12
12
12
Vacuum port
11
Hose strap
12
12
Disposable dust bag
DESCRIPTION (Fig. A)
ASSEMBLY AND ADJUSTMENTS (Fig. A–C)
OPERATION
INSTRUCTIONS FOR USE (Fig. A, D, E)
WARNING: Always observe the safety instructions
and applicable regulations.
1. Plug the power cord into an appropriate outlet.
2. Turn the on/off switch to the ON position ( I ).
3. The D
EWALT construction dust extractor is tted
with the D
EWALT connection system. It allows a
TO CONVERT BACK TO DRY VACUUM
OPERATION (Fig. A)
1. Empty dust tank, refer to TO EMPTY DUST TANK
instructions.
WARNING : Never modify the power appliance or
any part of it. Damage or personal injury could result.
fast, secure connection between the hose
and power tool. The connector connects
directly to D
EWALT compatible tools or through the
use of an adapter (available from local D
EWALT
supplier). If you need Install the adapters, refer to
Fig. E.
NOTE: If using an adapter ensure it is rmly
attached to the tool outlet before following the steps
below.
OPERATING INSTRUCTIONS
CASTER INSTALLATION (Fig. A, F)
1. Invert the dust tank and install the casters to the
bottom of the dust tank and x them with screws.
2. Return dust tank assembly upright.
REMOVE/CHANGE USED DISPOSABLE
DUST BAG (Fig. A)
WARNING: Appropriate personal protective
equipment like dust mask and gloves should be used
while handling used dust bags.
1. Turn off vacuum and unplug cord from outlet.
2. Unlatch lid latches and remove vacuum head .
3. Pull the disposable dust bag carefully from vacuum
port .
4. Seal the disposable dust bag opening tightly when
removing it from the machine.
5. Dispose the disposable dust bag in appropriate
container according to statutory provisions.
5
4
6
14
14
9
WET PICK UP APPLICATIONS (Fig. A, G)
WARNING: If foam or liquid escapes from the
machine,switch off immediately.
WARNING: Do not use the machine with this set
up for dust Class L.
The ball oat will block air to the motor when
the dust tank is full and the sound of the motor will
change at once.
When the motor has a high pitched sound and air/
water ow stops, empty the dust tank.
1. Turn off vacuum and unplug cord from outlet.
2. Unlatch lid latches and remove vacuum
head .
3. Empty contents of dust tank into a suitable container
or drain.
CAUTION: Clean the water level limiting device
regularly and examine it for signs of damage. Refer to
Fig. G.
NOTICE: DO NOT remove ball oat , doing so
will cause damage to the vacuum. The ball oat keeps
water from entering the motor.
Before using the vacuum for wet pick up:
• Ensure the dust tank is empty and free of excessive dust.
• Remove the lter .
WARNING: To reduce the risk of injury, turn
appliance off and disconnect appliance from
power source before installing and removing
accessories, before adjusting or changing
set-ups or when making repairs. An accidental
start-up can cause injury.
WARNING: The lter must always be in
place while vacuuming, except as described
under WET PICK UP APPLICATIONS under
OPERATION. When vacuuming ne dust, you
may also need to use an disposable dust bag to
make emptying the dust tank easier.
1. Install the disposable dust bag , as shown
in Fig. B.
NOTE: Be careful not to tear the bag. Place bag
securely onto vacuum port to provide a tight
seal for maximum dust collection performance.
2. Place the vacuum head onto the dust tank and
secure it by closing the lid latches .
3. Insert the end of hose into clip-in hose vacuum
port and tighten the end of hose to the tank.
4
4
5
2. Place dust tank upside down position until dry. DO
NOT use wet dust tank for dry pick up.
3. Place vacuum head on a level surface appliance dry.
4. Reinstall lters when vacuum head is dry. See Filters
under Maintenance.
5. When dust tank is dry place the vacuum head
onto the dust tank and secure it by closing the
lid latches .
