For installations in A 36 steel, 1/2" (13mm) is the recommended minimum edge distance.
SPACING
The recommended minimum distance between fastenings is 1-1/2" (38mm) center to
center for installations in ASTM A 36 steel.
FASTENER LENGTH SELECTION IN STEEL
For permanent applications when using pins in steel, first determine the thickness of
the fixture to be fastened. To this, add the thickness of the steel base material plus a
minimum of 1/4" (6mm) to allow for proper point penetration. This will be the minimum
fastener shank length required. Do not select a fastener length longer than that required
for the application.
An excessively long shank can burnish or polish the hole created in the steel
resulting in a reduction in load capacity.
For removable applications with threaded studs, the shank length required is equal
to the thickness of the steel base material plus a minimum of 1/4" (6mm) to allow for
proper point penetration. This will be the minimum fastener shank length required. Do
not select a shank length longer than that required for the application. An excessively
long shank can burnish or polish the hole created in the steel resulting in a reduction
in load capacity. To determine the minimum threaded length, add the thickness of the
fixture and the nut / washer thickness. The nut and washer thickness is equal to the
nominal thread diameter.
Do not over tighten threaded studs, the maximum tightening torque is listed in
the table below. Use of a nut setter is recommended to reduce the possibility of over
tightening the fasteners. For critical applications, perform a job site test.
POWDER LOAD SELECTION GUIDE
.25 CALIBER 10 LOAD STRIPS
CAT # POWER LEVEL LOAD COLOR BOX CTN MSTR CTN WT./ 100
50570-PWR 3 Green 100 1000 20000 .28
50574-PWR 4 Yellow 100 1000 20000 .28
50678-PWR 5 Red 100 1000 20000 .28
.25 CALIBER 10 LOAD STRIPS MASTER PACK
CAT # POWER LEVEL LOAD COLOR BOX CTN MSTR CTN WT./ 100
50572-PWR 3 Green 1000 20000 .33 .28
50576-PWR 4 Yellow 1000 20000 .33 .28
50580-PWR 5 Red 1000 20000 .33 .28
FASTENER SELECTION GUIDE
8mm HEAD DIAMETER DRIVE PINS: Shoots pins 12.7mm to 38.1mm
(1/2" to 1-1/2") length
.300" HEAD DIAMETER DRIVE PINS: Shoots pins 1/2" to 1-1/1" length
1/4" -20 THREADED STUDS
CAT # THREAD
LEN
THREAD
DIA
SHANK
LEN
SHANK
DIA
CTN MSTR
CTN
WT./
100
50322-PWR 3/4" 1/4" 1/2" (K) .145 100 1000 1.1
50326-PWR 3/4" .1/4" 3/4" .145 100 1000 1.2
50328-PWR 1/2" .1/4" 1" .145 100 1000 1.2
