11
ENGLISH
in the battery is below the usable limit, the fuel gauge will not
illuminate and the battery will need to berecharged.
NOTE: The fuel gauge is only an indication of the charge left on
the battery pack. It does not indicate tool functionality and is
subject to variation based on product components, temperature
and end‑userapplication.
Belt Hook and Magnetic Bit Holder (Fig.A)
(OptionalAccessories)
WARNING: To reduce the risk of serious personal
injury, DO NOT suspend tool overhead or suspend objects
from the belt hook. ONLY hang tool’s belt hook from a
workbelt.
WARNING: To reduce the risk of serious personal
injury, ensure the screw holding the belt hook issecure.
IMPORTANT: When attaching or replacing a belt hook or
magnetic bit holder, use only the screw that is provided. Be sure
to securely tighten thescrew.
A belt hook
11
and magnetic bit holder
13
can be be attached
to either side of the tool using only the screw
12
provided,
to accommodate left‑ or right‑handed users. If the hook or
magnetic bit holder is not desired at all, it can be removed from
thetool.
To move belt hook or magnetic bit holder, remove the screw
12
that holds it in place then reassemble on the opposite side. Be
sure to securely tighten thescrew.
Installing a Bit or Accessory into a
KeylessChuck (Fig.D)
WARNING: Do not attempt to tighten drill bits (or
any other accessory) by gripping the front part of the
chuck and turning the tool on. Damage to the chuck
and personal injury may result. Always lock off trigger
switch and disconnect tool from power source when
changingacces sories.
WARNING: Always ensure the bit is secure before starting
the tool. A loose bit may eject from tool causing possible
personalinjury.
Your tool features a keyless chuck
10
with one rotating sleeve
9
for one‑handed operation of the chuck. To insert a drill bit or
other accessory, follow thesesteps.
1. Turn tool off and remove batterypack.
2. Grasp the black sleeve of the chuck with one hand
and use the other hand to secure the tool. Rotate the
sleeve counterclockwise far enough to accept the
desiredaccessory.
3. Insert the accessory about 19mm into the chuck and
tighten securely by rotating the chuck sleeve clockwise with
one hand while holding the tool with the other. Your tool is
equipped with an automatic spindle lock mechanism. This
allows you to open and close the chuck with onehand.
Be sure to tighten chuck with one hand on the chuck sleeve and
one hand holding the tool for maximumtightness.
To release the accessory, repeat steps 1and 2above.
Speed Selection (Fig.A)
The tool features two speed settings for
greaterversatility.NOTE: Do not change speeds when the tool
is running. Always allow the tool to come to a complete stop
before changingspeed.
1. To select speed 1(high torque setting), turn the tool off and
permit it to stop. Slide the speed selector
7
back (away
from thechuck).
2. To select speed 2(high speed setting), turn the tool off and
permit it to stop. Slide the speed selector
7
forward (toward
thechuck).
If the tool does not change speeds, confirm that the speed
selection switch is completely engaged in the forward or
backposition.
Mode Selection (Fig.A)
The mode selection collar
6
can be used to select the correct
operating mode depending upon the plannedapplication.
To select, rotate the collar until the desired symbol aligns with
thearrow.
Symbol Mode
Drilling
1–15 Screwdriving (higher number = greater torque)
Hammerdrilling (DCD709 only)
Variable Speed Trigger and Forward/Reverse
Control Button (Fig.A, E)
The drill is turned on and off by pulling and releasing the
variable speed trigger
4
. The farther the trigger is depressed,
the higher the speed of the drill. Your tool is equipped with
a brake. The chuck will stop as soon as the trigger switch is
fullyreleased.
A forward/reverse control button
5
determines the rotational
direction of the tool and also serves as a lock‑offbutton.
• To select forward rotation, release the trigger and depress
the forward/reverse control button on the right side of
thetool.
• To select reverse, depress the forward/reverse control
button on the left side of thetool.
NOTE: The centre position of the control button locks the tool
in the off position. When changing the position of the control
button, be sure the trigger isreleased.
NOTE: Continuous use in variable speed range is not
recommended. It may damage the switch and should
beavoided.
NOTE: The first time the tool is run after changing the direction
of rotation, you may hear a click on start up. This is normal and
does not indicate aproblem.
