DeWalt XR DCD708 User Manual

ENGLISH
3
Congratulations!
You have chosen a DeWALT tool. Years of experience, thorough
product development and innovation make DeWALT one of the
most reliable partners for professional power toolusers.
Technical Data
DCD708 DCD709
Voltage
V
DC
18 18
Type
2 2
Battery type
Li‑Ion Li‑Ion
No‑load speed
1st gear
2nd gear
min‑1
min‑1
0–450
0–1650
0–450
0–1650
Beats per minute
1st gear
– 0–7650
2nd gear
– 0–28050
Max. Torque (hard/soft)
Nm 65/26 65/26
Chuck capacity
mm 1.5–13 1.5–13
Maximum drilling capacity
Wood
Metal
Masonary
mm
mm
mm
30
13
–
30
13
13
Weight (without battery pack)
kg 1.10 1.20
Noise values and/or vibration values (triax vector sum) according to
EN62841‑2‑1:
L
PA
(emission sound pressure
level)
dB(A) 72 86
L
WA
(sound power level) dB(A) 83 97
K (uncertainty for the given
sound level)
dB(A) 5 3
Drilling into metal
Vibration emission value a
h,D
= m/s
2
<2.5 3.3
Uncertainty K = m/s
2
1.5 1.5
Drilling into concrete
Vibration emission value a
h,ID
= m/s
2
– 14.5
Uncertainty K = m/s
2
– 1.5
Screwdriving
Vibration emission value
a
h
=
m/s
2
<2.5 <2.5
Uncertainty K = m/s
2
1.5 1.5
The vibration emission level given in this information sheet has
been measured in accordance with a standardised test given in
EN62841 and may be used to compare one tool with another. It
may be used for a preliminary assessment ofexposure.

WARNING: The declared vibration emission level
represents the main applications of the tool. However if
the tool is used for different applications, with different
accessories or poorly maintained, the vibration emission
may differ. This may significantly increase the exposure
level over the total workingperiod.
An estimation of the level of exposure to vibration should
also take into account the times when the tool is switched
off or when it is running but not actually doing the job.
This may significantly reduce the exposure level over the
total workingperiod.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool
and the accessories, keep the hands warm, organisation
of workpatterns.
EC-Declaration of Conformity
Machinery Directive
Drill/Driver/Impact Drill
DCD708, DCD709
DeWALT declares that these products described under
Technical Data are in compliance with:
2006/42/EC, EN62841‑1‑2015+AC:2015, EN62841‑2‑
1:2018+A11:2019.
These products also comply with Directive 2014/30/EU and
2011/65/EU. For more information, please contact DeWALT at
the following address or refer to the back of themanual.
The undersigned is responsible for compilation of the technical
file and makes this declaration on behalf ofDeWALT.
Markus Rompel
Vice President of Engineering, PTE‑Europe
DeWALT, Richard‑Klinger‑Straße 11,
65510, Idstein, Germany
06.12.2021
DECLARATION OF CONFORMITY
THE SUPPLY OF MACHINERY SAFETY
REGULATIONS 2008
Drill/Driver/Hammerdrill
DCD708, DCD709
DeWALT declares that these products described under Technical
Data are in compliancewith:
The Supply of Machinery (Safety) Regulations, 2008, S.I.
2008/1597 (as amended),
EN62841‑1‑2015+AC:2015, EN62841‑2‑1:2018+A11:2019.
English (original instructions)
CORDLESS COMPACT 13mm DRILL/DRIVER/HAMMERDRILL
DCD708, DCD709

DeWalt XR DCD708 Specifications

General

Max Torque (in-lbs)	300 in-lbs
Chuck Type	Keyless
Chuck Capacity	1/2 inch
No Load Speed	0-600 RPM
Weight	3.4 lbs
No Load Speed (alternative)	0-600 RPM
Battery Type	Li-Ion
Drilling Capacity (Metal)	13 mm
