Belt Hook and Magnetic Bit Holder (Fig.A)
Optional Accessories

WARNING: To reduce the risk of serious personal
injury, ONLY use the tool's belt hook to hang the
tool from a work belt. DO NOT use the belt hook for
tethering or securing the tool to a person or object during
use. DO NOT suspend tool overhead or suspend objects
from the belthook.

WARNING: To reduce the risk of serious personal
injury, ensure the screw holding the belt hook issecure.

CAUTION: To reduce the risk of personal injury or
damage, DO NOT use the belt hook to hang the drill
while using as aspotlight.
IMPORTANT: When attaching or replacing the belt hook
6
or
magnetic bit holder
8
, use only the mounting screw
7
that is
provided. Be sure to securely tighten thescrew.
The belt hook and magnetic bit holder can be be attached
to either side of the tool using only the screw provided, to
accommodate left- or right- handed users. If the hook or
magnetic bit holder is not desired at all, it can be removed from
thetool.
Deep Hex Pocket (Fig.A)
Your tool features a deep hex pocket
4
which is through and
behind the chuck
11
. This allows for a 51mm or longer 1/4"
hex shank bit to be inserted farther into the unit for close-up
applications. With the chuck jaws fully open (as described in
Installing a Bit or Accessory into a KeylessChuck) insert a 1/4"
hex shank bit fully into and through the chuck. The chuck can
then be tightened as stated under Installing a Bit or Accessory
into a KeylessChuck.
and personal injury may result. Always lock off trigger
switch and disconnect tool from power source when
changingacces sories.

WARNING: Always ensure the bit is secure before starting
the tool. A loose bit may eject from tool causing possible
personalinjury.
Your tool features a keyless chuck with one rotating sleeve
12
for
one-handed operation of the chuck. To insert a drill bit or other
accessory, follow thesesteps.
1. Turn tool off and remove batterypack.
2. Grasp the black sleeve of the chuck with one hand
and use the other hand to secure the tool. Rotate the
sleeve counterclockwise far enough to accept the
desiredaccessory.
3. Insert the accessory about 19mm into the chuck and
tighten securely by rotating the chuck sleeve clockwise with
one hand while holding the tool with the other. Your tool is
equipped with an automatic spindle lock mechanism. This
allows you to open and close the chuck with onehand.
Be sure to tighten chuck with one hand on the chuck sleeve and
one hand holding the tool for maximumtightness.
To release the accessory, repeat steps 1and 2above.
Installing a Bit or Accessory into a
KeylessChuck (Fig.A)

WARNING: Do not attempt to tighten drill bits (or
any other accessory) by gripping the front part of the
chuck and turning the tool on. Damage to the chuck
Worklight (Fig.A)
The worklight
5
is located between the chuck and the paddle
switch. The worklight is activated when the paddle switch is
depressed. When the paddle is released, the worklight will stay
illuminated for up to 20seconds.
NOTE: The worklight is for lighting the immediate work surface
and is not intended to be used as aflashlight.
Dual Range Gearing (Fig.A)
The dual range feature of your drill/driver allows you to shift
gears for greaterversatility.
1. To select speed 1(high torque setting), turn the tool off and
permit it to stop. Slide the gear shifter
3
forward (towards
thechuck).
2. To select speed 2(low torque setting), turn the tool off and
permit it to stop. Slide the gear shifter back (away from
thechuck).
NOTE: Do not change gears when the tool is running. Always
allow the drill to come to a complete stop before changing
gears. If you are having trouble changing gears, make sure that
the dual range gear shifter is either completely pushed forward
or completely pushedback.
Forward/Reverse Control Button (Fig.A)
A forward/reverse control button
2
determines the direction of
the tool and also serves as a lock-offbutton.
To select forward rotation, release the paddle switch and
depress the for ward/re verse control button on the right side of
thetool.
To select reverse, release the paddle switch and depress the
forward/reverse control button on the left side of thetool.
The centre position of the control button locks the tool in the
off position.
NOTE: When the tool is not in use or being transported, keep
the button in the middle lock position.
When changing the position of the control button, be sure the
trigger isreleased.
NOTE: The first time the tool is run after changing the direction
of rotation, you may hear a click on start up. This is normal and
does not indicate aproblem.
the faster the tool will operate. Use lower speeds for starting
holes without a centerpunch, drilling in metals or plastics,
driving screws and drilling ceramics. Higher speeds are better
for drilling in wood, wood compositions and for using abrasive
and polishing accessories. For maximum tool life, use variable
speed only for starting holes or fasteners.
NOTE: Continuous use in variable speed range is not
recommended. It may damage the switch and should
beavoided.
