Variable Speed Trigger Switch (Fig.A)
To turn the tool on, squeeze the variable speed
triggerswitch
1
. To turn the tool off, release the trigger switch.
Belt Hook and Magnetic Bit Holder (Fig.A)
Optional Accessories
WARNING: To reduce the risk of serious personal injury,
ONLY use the tool's belt hook to hang the tool from a work
belt. DO NOT use the belt hook for tethering or securing the tool
to a person or object during use. DO NOT suspend tool overhead
or suspend objects from the belthook.
WARNING: To reduce the risk of serious personal injury,
ensure the screw holding the belt hook issecure.
CAUTION: To reduce the risk of personal injury or
damage, DO NOT use the belt hook to hang the drill while
using as aspotlight.
IMPORTANT: When attaching or replacing the belt hook
10
or
magnetic bit holder
12
, use only the mounting screw
11
that
is provided. Be sure to securely tighten thescrew.
The belt hook and magnetic bit holder can be attached to either
side of the tool using only the screw provided, to accommodate
left- or right-handed users. If the hook or magnetic bit holder is
not desired at all, it can be removed from thetool.
To move belt hook or magnetic bit holder, remove the screw
that holds it in place, then reassemble on the opposite side. Be
sure to securely tighten thescrew.
Inserting and Removing the Battery Pack from the
Tool (Fig.B)
NOTE: Make sure your battery pack
7
is fullycharged.
To Install the Battery Pack into the Tool Handle
1. Align the battery pack with the rails inside the tool’s
handle(Fig. B).
2. Slide it into the handle until the battery pack is firmly seated
in the tool and ensure that you hear the lock snap intoplace.
To Remove the Battery Pack from the Tool
1. Press the battery release button
8
and firmly pull the battery
pack out of the toolhandle.
2. Insert battery pack into thecharger.
Fuel Gauge Battery Packs (Fig.B)
Some DeWALT battery packs include a fuel gauge, which
consists of three green LED lights that indicate the level of
charge remaining in the batterypack.
To actuate the fuel gauge, press and hold the fuel gauge
button
14
. A combination of the three green LED lights will
illuminate, designating the level of charge left. When the level
of charge in the battery is below the usable limit, the fuel gauge
will not illuminate and the battery will need to berecharged.
NOTE: The fuel gauge is only an indication of the charge left on
the battery pack. It does not indicate tool functionality and is
subject to variation based on product components, temperature
and end-userapplication.
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of serious personal injury,
turn tool off and disconnect battery pack before making
any adjustments or removing/installing attachments or
accessories. An accidental start-up can causeinjury.
WARNING: Use only DeWALT batteries andchargers.
Description (Fig. A)
WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1
Trigger switch
2
Forward/reverse control button
3
Torque adjustment collar
4
Gear shifter
5
Worklight
6
Keyless chuck
7
Battery pack
8
Battery release button
9
Main handle
10
Belt hook (included with some models)
11
Screw
12
Magnetic bit holder (included with some models)
13
Date Code
Intended Use
These drills/drivers/hammerdrills are designed for professional
drilling, percussion drilling and screwdrivingapplications.
DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
These drills/drivers/hammerdrills are professional powertools.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
withoutsupervision.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or mental
abilities; lack of experience, knowledge or skills unless they are
supervis`ed by a person responsible for their safety. Children
should never be left alone with thisproduct.
Markings on Tool
The following pictograms are shown on the tool:
a
Read instruction manual beforeuse.
n
Visible radiation. Do not stare intolight.
Date Code Position (Fig.A)
The production date code
13
consists of a 4-digit year followed
by a 2-digit week and is extended by a 2-digit factorycode.
SAVE THESE INSTRUCTIONS
Battery Type
These battery packs may be used:
Battery (kg) Battery (kg)
DCB546 1.08 DCB184/B/G 0.62
DCB547/G 1.46 DCB185 0.35
DCB548 1.46 DCB187 0.54
DCB549 2.12 DCB189 0.54
DCB181 0.35 DCBP034/G 0.32
DCB182 0.61 DCBP518/G 0.75
DCB183/B/G 0.40
Refer to the battery/charger manual for moreinformation.
