ENGLISH
21
Screwdriver Operation (Fig.D)
1. Select the desired speed/torque range using the dual
range gear selector to match the speed and torque of the
plannedoperation.
2. Turn the torque adjustment collar
3
to the desired position.
Lower numbers indicate lower torque settings; higher numbers
indicate higher torquesettings.
3. Insert the desired fastener accessory into the chuck as you
would any drillbit.
4. Make some practice runs in scrap or on unseen areas to
determine the proper position of the clutchcollar.
5. Always start with lower torque settings, then advance to
higher torque settings to avoid damage to the workpiece
orfastener.
Drill Operation (Fig.E)
WARNING: To reduce the risk of serious personal injury, turn
tool off and disconnect tool from power source before making any
adjustments or removing/installing attachments oraccessories.
WARNING: TO REDUCE THE RISK OF PERSONAL INJURY,
ALWAYS ensure workpiece is anchored or clamped firmly. If
Proper Hand Position (Fig.C)
WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position as shown.
WARNING: To reduce the risk of serious personal injury,
ALWAYS hold securely in anticipation of a suddenreaction.
Proper hand position requires one hand on the main handle
9
and the other hand holding the battery pack
7
.
OPERATION
Instructions for Use
WARNING: Always observe the safety instructions and
applicableregulations.
WARNING: To reduce the risk of serious personal injury,
turn tool off and disconnect battery pack before making
any adjustments or removing/installing attachments or
accessories. An accidental start-up can causeinjury.
Always lock off trigger switch and remove the battery from the
tool when changingacces sories.
WARNING: Always ensure the bit is secure before starting
the tool. A loose bit may eject from tool, causing possible
personalinjury.
Your tool features a keyless chuck
6
with one rotating chuck
sleeve
15
for one-handed operation of the chuck. To insert a
drill bit or other accessory, follow thesesteps.
1. Turn tool off and remove the batterypack.
2. Grasp the black sleeve of the chuck with one hand and
use the other hand to secure the tool. Rotate the sleeve
anticlockwise (as viewed from the front) far enough to accept
the desiredaccessory.
3. Insert the accessory about 19mm into the chuck and tighten
securely by rotating the chuck sleeve clockwise with one hand
while holding the tool with the other hand. Continue to rotate
the chuck sleeve until several ratchet clicks are heard to ensure
full grippingpower.
NOTE: Be sure to tighten chuck with one hand on the chuck
sleeve and one hand holding the tool for maximumtightness.
To release the accessory, repeat steps 1and 2above.
Keyless Single Sleeve Chuck (Fig.G–I)
WARNING: Do not attempt to tighten drill bits (or any other
accessory) by gripping the front part of the chuck and turning
the tool on. Damage to the chuck and personal injury may result.
Worklight (Fig.A)
There is a worklight
5
located just above the trigger switch
1
.
The worklight is activated when the trigger switch is depressed.
When the trigger is released, the worklight will stay illuminated
for up to 20seconds.
NOTE: The worklight is for lighting the immediate work surface
and is not intended to be used as aflashlight.
Dual Range Gearing (Fig.A)
The dual range feature of your drill/driver allows you to shift
gears for greaterversatility.
1. To select speed 1(high torque setting), turn the tool off
and permit it to stop. Slide the gear shifter
4
forward (towards
thechuck).
2. To select speed 2(low torque setting), turn the tool off
and permit it to stop. Slide the gear shifter back (away from
thechuck).
NOTE: Do not change gears when the tool is running. Always
allow the drill to come to a complete stop before changing
gears. If you are having trouble changing gears, make sure that
the dual range gear shifter is either completely pushed forward
or completely pushedback.
Torque Adjustment Collar (Fig.A, D–F)
Your tool has an adjustable torque screwdriver mechanism for
driving and removing a wide array of fastener shapes and sizes
and in some models, a hammer mechanism for drilling into
masonry. Circling the torque adjustment collar
3
are numbers,
a drill bit symbol, and on some models, a hammer symbol.
These numbers are used to set the clutch to deliver a torque
range. The higher the number on the collar, the higher the
torque and the larger the fastener which can be driven. To select
any of the numbers, rotate until the desired number aligns with
thearrow.
Forward/Reverse Control Button (Fig.A)
A forward/reverse control button
2
determines the direction of
the tool and also serves as a lock-offbutton.
To select forward rotation, release the trigger switch and
depress the for ward/re verse control button on the right side of
thetool.
To select reverse, release the trigger switch and depress the
forward/reverse control button on the left side of thetool.
The centre position of the control button locks the tool in the off
position. When changing the position of the control button, be
sure the trigger isreleased.
NOTE: The first time the tool is run after changing the direction
of rotation, you may hear a click on start-up. This is normal and
does not indicate aproblem.
Your tool is equipped with a brake. The chuck will stop as soon
as the trigger switch is fullyreleased.
NOTE: Continuous use in variable speed range is not
recommended. It may damage the switch and should
beavoided.
