DeWalt XR DCD991P2 - Package Contents; Assembly and Adjustments

10
ENGLISH
Inserting and Removing the Battery Pack
from the Tool (Fig.C)
NOTE: Make sure your battery pack
1
is fullycharged.
To Install the Battery Pack into the Tool Handle
1. Align the battery pack
1
with the rails inside the tool’s
handle (Fig. C).
ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.

WARNING: Use only DeWALT battery packs andchargers.
Description (Fig. A)

WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
Components
1
Battery pack
2
Battery release button
3
Variable speed trigger switch
4
Forward/reverse control button
5
Torque adjustment collar
6
Keyless chuck
7
Chuck sleeve
8
Speed selector
9
Worklight
10
Worklight switch
11
Belt hook (Optional accessory)
12
Mounting screw
13
Bit holder (Optional accessory)
14
Side handle
15
Main handle
Intended Use
These hammerdrills are designed for professional drilling,
percussion drilling and screwdrivingapplications.
DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
These drills/drivers/hammerdrills are professional powertools.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
withoutsupervision.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
Date Code Position (Fig.B)
The date code
16
, which also includes the year of manufacture,
is printed into thehousing.
Example:
2020XX XX
Year and Week of Manufacture
Markings on Tool
The following pictograms are shown on the tool:
a
Read instruction manual beforeuse.
n
Visible radiation. Do not stare intolight.
Package Contents
The package contains:
1 Brushless cordless drill/driver (DCD991)
1 Brushless cordless hammerdrill (DCD996)
1 Charger
1 Side handle
1 Magnetic bit holder (Optional accessory)
1 Belt hook (Optional accessory)
1 Li-Ion battery pack (C1, D1, E1, L1, M1, P1, S1, T1, X1, Y1models)
2 Li-Ion battery packs (C2, D2, E2, L2, M2, P2, S2, T2, X2, Y2models)
3 Li-Ion battery packs (C3, D3, E3, L3, M3, P3, S3, T3, X3, Y3 models)
1 Instruction manual
NOTE: Battery packs, chargers and kitboxes are not included
with N models. Battery packs and chargers are not included with
NT models. Bmodels include Bluetooth® batterypacks.
NOTE: The Bluetooth® word mark and logos are registered
trademarks owned by the Bluetooth®, SIG, Inc. and any use of
such marks by DeWALT is under license. Other trademarks and
trade names are those of their respectiveowners.
• Check for damage to the tool, parts or accessories which may
have occurred duringtransport.
• Take the time to thoroughly read and understand this manual
prior tooperation.
Battery Type
The following tools operate on a 18 volt battery pack:
DCD991, DCD996.
These battery packs may be used: DCB181, DCB182, DCB183,
DCB183B, DCB183G, DCB184, DCB184B, DCB184G, DCB185,
DCB187, DCB189DCB546, DCB547. Refer to Technical Data for
moreinformation.
z
Do not incinerate the batterypack.
B
USE (without transport cap). Example: Wh rating
indicates 108Wh (1battery with 108Wh).
A
TRANSPORT (with built-in transport cap). Example: Wh
rating indicates 3x 36Wh (3batteries of 36Wh).
