11
ENGLISH
Quick-Change Chuck (Fig. A, F)
NOTE: The chuck accepts 6.35 mm hexaccessories.
Place the forward/reverse control lever
6
in the lock-off (centre)
position and remove battery pack before changingaccessories.
To install an accessory, pull the quick-change sleeve
2
away
from the front of the tool then fully insert the accessory into
the quick-change chuck
1
. When the sleeve is released, the
accessory is locked into place (Fig.F).
To remove an accessory, pull the quick-change sleeve
2
away
from the front of the tool, then remove the accessory from the
quick-release chuck
1
(Fig.F).
Versa Clutch™ (Fig. G)
This tool features the Versa Clutch™ which allows a wide range
of fastener sizes. To adjust:
1. Pull forward, then rotate clutch collar
5
in the "Increase"
direction as indicated on adjustment collar
3
, to increase
the amount of clutch engagement and torque output.
Maximum rotation of the collar in the "Increase" direction
results in full clutch engagement and maximum torque
output and fastener capacity. The collar and adjustable stop
will not screw off the clutchhousing.
2. If after pushing the screw into the work piece there is no
chuck rotation, check the adjustment range on the collar
marked MAX/MIN
4
. Rotate the collar to increase the
clutchengagement.
3. Test drive a fastener into a scrap piece to check proper
fastener seating. It is normal after a period of use to
require a slightly different collar setting due to wear on the
clutchfaces.
NOTE: With Versa Clutch™, the operator has the ability to
“override” clutch ratchet if a fastener hits a wood knot, variable
hardness in steel work pieces or incorrect pilot holes. Increased
operator pressure will usually cause the clutches to pick-up
and continue to seat the fastener. Further, a quick twist of the
collar will change the clutch setting to overcome most driving
difficulties and will provide for immediate change in torque
output giving the operator the option to drive a wide range of
fastenersizes.
MAINTENANCE
Your
power tool has been designed to operate
over a long period of time with a minimum of maintenance.
Continuous satisfactory operation depends upon proper tool
care and regularcleaning.
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.
The charger and battery pack are notserviceable.
Cleaning
WARNING: Blow dirt and dust out of the main housing
with dry air as often as dirt is seen collecting in and around
the air vents. Wear approved eye protection and approved
dust mask when performing thisprocedure.
WARNING: Never use solvents or other harsh chemicals
for cleaning the non-metallic parts of the tool. These
chemicals may weaken the materials used in these parts.
Use a cloth dampened only with water and mild soap.
Never let any liquid get inside the tool; never immerse any
part of the tool into aliquid.
Optional Accessories
WARNING: Since accessories, other than those offered
by
, have not been tested with this product, use
of such accessories with this tool could be hazardous.
To reduce the risk of injury, only
recommended
accessories should be used with thisproduct.
Consult your dealer for further information on the
appropriateaccessories.
Protecting the Environment
Separate collection. Products and batteries marked
with this symbol must not be disposed of with normal
householdwaste.
Products and batteries contain materials that can
be recovered or recycled reducing the demand for raw
materials. Please recycle electrical products and batteries
according to local provisions. Further information is available at
www.2helpU.com.
Rechargeable Battery Pack
This long life battery pack must be recharged when it fails to
produce sufficient power on jobs which were easily done before.
At the end of its technical life, discard it with due care for our
environment:
• Run the battery pack down completely, then remove it from
thetool.
• Li-Ion cells are recyclable. Take them to your dealer or a
local recycling station. The collected battery packs will be
recycled or disposed ofproperly.
