Dexing NDS3244S - Product Information; Order Information; Appearance and Illustration

NDS3244S Multi-Channel Encoder User Manual
3
1.5 Order Information
P/N
Config
NDS3244S
24 HDMI inputs
1.6 Appearance and Illustration
Front Panel Illustration:
1U chassis (three encoder modules) illustration：
1 2
1
Run and Power indicators for 3 modules
2
NMS (Network Management Port)
Data Port (for IP Signal Output)
Rear Panel Illustration:
1 2 3 4 5
