4
Chapter3 Main chip functions and the introductions of power supply
3-1 Main IC and functions of HLS80JS
UM2:Flash Memory
UM1: MSD3663
UTO1
UE2:DC-DC
UE4:LDO
USO1
UE3:LDO
UE1:DC-DC
UZ1:LNB
UA1: Amplifier
