Deye DGA1-ACDCBLW-18K User Manual

Revision 10 Nov 2020 Page 8 of 32
The indoor hole must be higher than the outdoor hole so that condensate water will drain.
Outdoor unit mounting Instructions
Install the condensate drain if required. The outdoor unit will condense water when the
system is in heating mode. Consult local regulations for drainage connections.
Mount the unit on an approved wall mounting bracket and secure or mount the unit on a
secure waterproof surface and secure.
Outdoor unit required clearances
Outdoor unit Clearances
Above
500 mm
Left
300 mm
Right
60 mm
Below
200
Behind
300
