DeZurik G Series Instruction

DeZURIK
Cylinder Operated G-Series Actuator
D10022 Page 12 August 2012
Installing Cylinder (Continued)
Table E: Rack Rod Spring Washer Arrangement
Valve Size
Actuator Size
Direct
Pressure
Reverse
Pressure
in mm
4
100
ALL
A
A
5
125
ALL
B
B
6
150
ALL
B
B
8 200
G6
B
B
G12
A
A
10 250
G6
B
B
G12
A
B
12 300
G6
B
B
G12
B
B
G16
A
A
14 350
G12
B
B
G16
A
A
16
400
ALL
B
B
18
450
ALL
B
B
20
500
ALL
B
B
24 600
G16-C8
B
C
G16-C10
B
B
G16-C12
B
C
G16-C10B10
B
B
G16-C10B12
B
-
G16-C12B12
-
C
G16-C12B10B10
B
-
G16-C12B12B12
B
-
30 750
G16-C8
C
C
G16-C10
B
B
G16-C12
B
C
G16-C10B10
-
C
G16-C10B12
B
-
G16-C12B12
C
C
G16-C12B10B10
B
C
G16-C12B12B12
B
C
36 900
G16-C10B12
C
-
G16-C12B12
-
C
G16-C12B10B10
C
-
G16-C12B12B12
C
C
