12
Quick Setup Guide
Quick Setup
Guide
1.3.3 Parallel Port
Parallel Port
1.3.4 Serial Ports
COM 2
(J50)
COM 1
Serial Port
One card-edge bracket mounted
with a serial port cable is provided
for connecting the COM 2
secondary serial port.
