Document: DGP-2 & DGP-2-V2 Tungsten Grinder Product User Manual | Released: 5/13, Rev. A
RIGHT SIDE OF DGP-2 PRECISION TUNGSTEN GRINDER
ITEM PART NUMBER DESCRIPTION QTY
1 DGP-F007 ANGLE POINTER 1
2 DGP-F025 ANGLE SCALE 1
3 DGP-F142 WHEEL ARBOR 1
4 DGP-P177 BOLT - HEX - 3/8” - 16 x 3/4” HEXBOLT HEAD 1
5 DGP-F060 COLLET - .040” (1.0mm)
DGP-F070 COLLET - 1/16” (1.6mm)
DGP-F080 COLLET - 3/32” (2.4mm)
DGP-F090 COLLET - 1/8” (3.2mm)
DGP-F100 COLLET - 5/32” (4.0mm)
DGP-F110 COLLET - 3/16” (4.8mm)
6 DGP-P662-A EYESHIELD BRACKET SET R/S 1
7 DGP-P663-A EYESHIELD PLEXIGLASS R/S 1
8 DGP-P410 HANDLE - ADJUSTABLE CLAMPING 3
9 DGP-P460 KNOB - #10 SHEAR-LOC - BLACK 1
10 DGP-P440 KNOB - #6 SHEAR-LOC - BLACK 1
11 DGP-P310 BOLT - HEX - 3/8” 16 X 1 1
12 DGP-F231 NUT - HEX 1/2”-12 RH THREAD 1
13 DGP-F200 PIVOT BUSHING (GRINDING) 10-32 1
14 DGP-F277 RIGHT WHEEL INSIDE COVER 1
15 DGP-F278 RIGHT WHEEL OUTSIDE COVER 1
16 DGP-F225 SCALE SUPPORT BAR 1
17 DGP-P661 SCREW - BHC - #10-32 X 1” - ALLOY - BLACK 2
18 DGP-P1442 SCREW - BHC - #10-32 X 1/2” - ALLOY - BLACK 4
19 DGP-P660 SCREW - BHC - #10-32 X 1-1/4” - ALLOY - BLACK 1
20 DGP-P541 SCREW - BHC - #6-32 X 1/4” - ALLOY - BLACK 1
21 DGP-P1320 SCREW - BHC - #6-32 X 3/8” - ALLOY - BLACK 1
22 DGP-P570 SCREW - BHC - #8-32 X 1/2” - ALLOY - BLACK 2
23 DGP-PG536 SCREW - FLANGED - 1/4”-20 X 1/2” 3
24 DGP-P178 SCREW - PAN HEAD - #10-24 X 3/8” 3
25 DGP-PG1439 SCREW - SET - 1/4”-20 X 3/8” - ALLOY - BLACK 2
26 DGP-PG1320 SCREW - SHC - #6-32 X 3/8” - ALLOY - BLACK 2
28 DGP-PG1363 SCREW - SHC - #10-32 X 1” - ALLOY - BLACK 1
29 DGP-P542 SCREW BHSCH BLK #8-32 X 1/2” 2
30 DGP-F230 SUPPORT BRACKET 1
31 DGP-F222 UPRIGHT BAR 1
32 DGP-P730 WASHER - FLAT - #10 X 1/2” OD X 3/32” 4
33 DGP-P725 WASHER - FLAT 3/8” 3
34 DGP-P724 WASHER - SPLIT LOCK 3/8” 2
35 DGP-PG1426 WHEEL - DIAMOND - 300 GRIT (STANDARD) 1
DGP-PG1425 WHEEL - DIAMOND - 600 GRIT (OPTIONAL) 1
36 DGP-F242 X-AXIS CLAMP BLOCK 1
37 DGP-F245 X-AXIS GUIDE BAR 1
38 DGP-F255 Y-AXIS CLAMP BLOCK 1
39 DGP-F260 Z-AXIS CLAMP BLOCK 1
40 DGP-F270 Z-AXIS GUIDE BRACKET 1
41 DGP-P400 GRINDER - BENCH 6” SINGLE PHASE 1/3 HP 1
42 DGP-F180-A BLOCK POINT FLAT DRESSER 1
43 DGP-P550 SCREW SET SHC CUP 1
44 DGP-P179 1/4”-20 X 3/8” KNOB 1
45 DGP-PG1334 1/4” WASHER FLAT SS 1
CHOICE
OF 4
Page 12
