Document: DGP-2 & DGP-2-V2 Tungsten Grinder Product User Manual | Released: 5/13, Rev. A
Page 10
LEFT SIDE OF DGP-2 PRECISION TUNGSTEN GRINDER
ITEM PART NUMBER DESCRIPTION QTY
1 DGP-F010-A ARBOR SPACER 1
2 DGP-P307 BASE - ELECTRODE - LEFT SIDE - MOD FOR DGP-2 & -3 1
3 DGP-P310 BOLT - HEX HD - 3/8”-16 X 1 SST 2
4 W/GRINDER CARRIAGE BOLT 5/16-18 X 1-1/2 3
5 EYESHIELD BRACKET SET 4
6 EYESHIELD PLEXIGLAS 1
7 DGP-F120 SECONDARY SAFETY STRIP 1
8 DGP-F167-A HUB - INNER FOR DGP-2 AND 3 LEFT SIDE 1
9 DGP-F175-A HUB - OUTER FOR DGP-2 AND 3 LEFT SIDE 1
10 DGP-P460 KNOB - #10 SHEAR-LOC - 5/8 OD - BLACK 1
11 W/GRINDER LEFT WHEEL INSIDE COVER 1
12 W/GRINDER LEFT WHEEL OUTSIDE COVER 1
13 DGP-F232 NUT - HEX - 5/16-18 2
14 DGP-P494 NUT - HEX - LOCKING NYLON INSERT - #10-32 STL 2
15 DGP-F233 NUT - HEX 1/2-12 LH THREAD 1
16 DGP-PG1396 SCREW - BHC - 1/4-20 X 1/2 - ALLOY - BLACK 2
17 W/GRINDER SCREW - FLANGED - 1/4-20 X 1/2 3
18 W/GRINDER SCREW - PAN HEAD - #10-24 X 3/8 3
19 DGP-PG1397 SCREW - SHC - #10-32 X 5/8 SST 1
20 W/GRINDER SPACER - 5/16 ID X 19/32 OD X 3/8 1
21 DGP-F050 SUPPORT ARM - LEFT SIDE 1
22 W/GRINDER UPRIGHT BAR 1
23 W/GRINDER UPRIGHT BAR (CUT IN HALF) 1
24 DGP-P700 WASHER - FLAT - 1/4 ID X 1/2 OD X .05 SST 2
25 DGP-P705 WASHER - FLAT - 1/4 X 5/8 SST 1
26 DGP-P725 WASHER - FLAT - 3/8 1
27 W/GRINDER WASHER - FLAT 5/16 4
28 W/GRINDER WASHER - LOCK 5/16 3
29 W/GRINDER MOTOR SHAFT - LEFT SIDE 1
30 W/GRINDER MOTOR HOUSING - LEFT SIDE 1
31 DGP-P735 WHEEL - CUT-OFF 1
32 DGP-F040 BLOCK - DGP-2 CUT-OFF INDEXER 1
- DGP-F130 CUT-OFF FORK ASSY FOR DGP-2 1
33 - BAR - RULER SUPPORT 1
34 - CUT-OFF FORK 1
35 DGP-F190 PIVOT BLOCK FOR DGP-2 & -3 1
36 DGP-F205 PIVOT SHAFT FOR DGP-2 & -3 1
37 - SCREW - SET - #4-40 X 3/16 SST 1
38 DGP-F150 HANDLE - DGP-2 CUT OFF INDEXER 1
39 DGP-P450 KNURLED KNOB - #8 SHCS - 1/2 OD - BLACK 1
40 DGP-P520 SCALE - DGP-2 - INCH - SST FLEX (STANDARD) 1
DGP-P530 SCALE - DGP-2 - METRIC - SST FLEX (OPTIONAL) 1
41 DGP-P610 SCREW - FHS - #2-56 X 1/8 - SST 2
42 DGP-PG1387 SCREW - SHC - #10-32 X 1/2 - ALLOY - BLACK 2
43 DGP-P570 SCREW - SHC - #6-32 X 1/2 - ALLOY - BLACK 1
44 DGP-P570 SCREW - SHC - #8-32 X 1/2 - ALLOY - BLACK 1
45 DGP-P550 SCREW - SET - #8-32 X 3/16 - CUP POINT - ALLOY - BLACK 1
46 DGP-P723 WASHER - FLAT - #10 X 7/16 OD X .05 THK SST 2
47 DGP-PG1398 WASHER - SPLIT LOCK - #6 SST 1
48 DGP-PG1399 SCREW - SHC - 3/8-16 X 3/4 - ALLOY - BLACK 1
DGP-P662-A
