DHP 10125-M - Assembly Step 5: Final Touches; Add Slat Spacers and Ladder

DETAIL 2
DETAIL 1
11 /15
5
For the upper bed, attach 19 SLAT SPACERS (R) between SLATS (K) as shown in DETAIL (1). Repeat the same procedure for
the lower bed.
Attach the LADDER (L) to the LADDER SIDE RAIL (H) with the BOLTS (6) as shown in DETAIL (2).
Hardware Required
x 2
B34541709603
L
H
L
6
C
K
K
N
N
6
