DHP 3135196 - Step 6: Attaching Ladder and Belts

12 /16
7
4
1
4
7
1
L
I
I
N
L
H
H
I
I
I
6
Attach the LADDER (L) to the LADDER SIDE RAIL (H) with the BOLTS (1) and NUTS (7) as shown. Attach the BELTS (N) to
the END GUARD RAILS (I) on both the upper and lower levels with the SCREWS (4) as shown.
Hardware Required
x2
x2
x4
B34313519600
