DHP 3136096 - Assembly Step 2: Side Rail and Ladder Attachment; Connecting Side Guard and Safety Rails; Attaching Ladder to Side Rails

8 /16
5
5
2
1
A
D
O
I
L
H
L
H
A
L
A
I
O
1
2
2
1
2
Hardware Required
x16
Attach the SIDE GUARD RAIL (I) to the REAR POST 1 (A) and the FRONT POST 2 (D) with the BOLTS (2). Attach the SIDE
SAFETY RAIL (H) to the REAR POST 1 (A) and the FRONT POST 2 (D) with the BOLTS (2). Attach the LADDER (L) to the
SIDE GUARD RAIL (I) and the SIDE SAFETY RAIL (H) with the BOLTS (1) and NUTS (5) at the bottom of the LADDER as
shown.
This is the right end assembly. Repeat this proceedure to create the left side assembly.
B34313609600
x4
x4
