Hardware Pack
Hardware Pack #: T3247298-02
Please do not completely tighten all the hardware,
until the entire assembly is complete, unless
otherwise indicated in the step-by-step
instructions.
The screw(s), bolt(s) to be used at each step are
shown in actual size in the lower right corner of
the page.
7
8
5
6
4
3
1
1/4" X 1 9/16"
X 4
1/4" X 7/8"
X 12
5/16" X 3/4"
X 16
1/4" X 11/16"
X 4
1/4"
X 4
4mm
X 1
Wrench
X 1
2
1/4" X 1 3/16"
X 8
