Hardware Pack
B344120019WE00
Hardware Pack #: T4120019WE-00
Please do not completely tighten all the hardware,
until the entire assembly is complete, unless
otherwise indicated in the step-by-step
instructions.
The screw(s), bolt(s) to be used at each step are
shown in actual size in the lower right corner of
the page.
6
3
2
1
1/4" X 2 3/4"
X 2
1/4" X 1 11/16"
X 4
1/4" X 7/8"
X 16
5/16" X 3/4"
X 8
1/4" X 11/16"
X 4
4.2 X 10mm
X 4
4mm
X 1
4
5
7
