DHP 5512098 - Page 15

15 /32
B34551209801
9
7
X 12
Attach (N) to (I2) with SREWS (7) then attach (N) to (F1) with SCREWS (7).
NOTE: Please ensure a clearance between (I2) and (B2)
to avoid scratching between the two parts.
9.1
9.2
N
I2
I2
F1
