7. Remove/Install the IC-A200 VHF Air Band Transceiver
A. Remove the IC-A200 VHF Air Band Transceiver
B. Install the IC-A200 VHF Air Band Transceiver
Detail Steps/Work Items Key Items/References
1. Open the related circuit-breaker.
2. Put a 3/32 allen wrench into the access hole for
the locking screw in the front panel. Engage
the screw.
Refer to Figure 201.
3. Turn the screw counter-clockwise until the unit
disengages from the mounting rack.
CAUTION:
DO NOT PULL ON THE KNOBS. DO NOT PRY THE FACE-PLATE.
YOU CAN DAMAGE THE UNIT.
CAUTION:
DO NOT TOUCH THE CONNECTOR CARD AT THE REAR OF THE
UNIT. THE ELECTROSTATIC CHARGE ON YOUR BODY CAN
DAMAGE THE UNIT.
4. Pull gently on the sides of the unit to remove it
from the mounting rack.
5. Install the protective covers on the rear
connectors of the unit.
Detail Steps/Work Items Key Items/References
1. Remove the protective covers from the rear
connectors on the unit.
2. Visually make sure that the metal catch on top
of the transceiver is engaged.
3. Insert the transceiver slowly into the mounting
rack.
Refer to Figure 201.
4. Insert a 3/32 inch allen wrench into the hole in
the front panel.
CAUTION:
DO NOT OVER-TIGHTEN THE LOCKING SCREW. YOU CAN
DAMAGE THE LOCKING MECHANISM.
5. Turn the locking screw clockwise until the
screw stops.
6. Close the circuit-breaker.
7. Do an operational test. Refer to paragraph 7.C.
