Diamondback 1260Sc - Page 10

P/N DESCRIPTION Qty P/N DESCRIPTION Qty
A1 MAINFRAME 1 A46 SLIDERAILS 1
A2 CHAINCOVER(R) 1 A47 CONSOLETUBE 1
A3 CHAINCOVER(L) 1 A48 ADJUSTINGBOARD 1
A4 FOAMDOUBLEͲSIDEDADHESIVE 2 A49 DJJACK 1
A5 CRANK 2 A50 BUSH 2
A6 CRANKCAP 2 A51 HANDLE 2
A7 NUT 2 A52 GENERATORCONTROLPLATE 1
A8 WASHER 2 A53 SPRING 2
A9 SCREWM4X16 6 A54 SCREWM5X40 2
A10 TURINGPLATECOVER 2 A55 BRAKEPAD 2
A11 SCREWM5X10 13 A56 SPRING 2
A12 ALUMINUMRING 1 A57 AXLE 2
A13 FLYWHEEL 1 A58 BELT2PJͲ1016 1
A14 BEARING(6004) 4 A59 SCREWM5X12 2
A15 SMALLBELTWHEEL 1 A60 WASHERM5 2
A16 NUTM10 2 A61 SPRING 1
A17 WASHERM10 2 A62 GENERATORFIXEDPLATE 1
A18 NUTM17 2 A63 SCREWM6X60 1
A19 AXLE 1 A64 GENERATORSHAFT 1
A20 SCREWM6X50 2 A65 WASHERM6 3
A21 NUTM20X12T 1 A66 NUTM6 1
A22 BELT
5PKͲ1387
1
A67 SCREWM6X12 1
A23 DRIVINGWHEEL 1 A68 GENERATOR 1
A24 AXLE 1 A69 SPRING 1
A25 SPRINGWASHERM8 4 A70 SCREWM5X12 2
A26 SCREWM8X15 4 A71 SENSORWIRE 1
A27 SCREWM8X60 2 A72 SENSORWIREHOUSING 1
A28 TENSIONASJUSTER 1 A73 SENSORWIREHOUSINGSCREW 1
A29 TENSIONCABLE 1 A74 WASHER 2
A30 MAGNETICHOUSING 1 A75 NUTM8 2
A31 SCREWM6X15 2 A76 BATTERY 1
A32 WASHERM6 4 A77 SCREWM6X16 1
A33 NUTM6 2 A78 PULLEY 1
A34 PLASTICPIPE 2 A79 HANDLE 1
A35 BUSHINGPAD 6 A80 FIXINGPAD 2
A36 SCREWM5X8 1 A81 SCREWM3X8 8
A37 SADDLESUPPORTTUBE 1 A82 SECTORPAD 2
A38 KNOB 2 A83 WASHERM6 2
A39 ENDCAP 4 A84 SCREWM6X40 1
A40 SCREWSLEEVE 2 A85 LEVERCOVER(R) 1
A41 SCREWM4X10 2 A86 LEVERCOVER
(L) 1
A42 ADJUSTING
BOARD
1
A87 NUTM5 2
A43 SCREWM3X6 2 A88 SMALLCAP 2
A44 SCREWM6X10 5 A89 TENSIONWHEEL 1
A45 ENDCAP 4 A90 NUTM6 1

