Diamondback 1260Sc - Assemble Saddle; Assemble Pedals

USE TOOL: #13 #14
#15 #17
Put the saddle (G) onto sliding basement and using tool to tight it.
G
Fix the Right Pedal(screw clockwise)
and left Pedal(screw counter-clockwise)
to the crank.
USE TOOL: #13 #14
#15 #17
K1
K2
FIGURE 6
FIGURE 6 -
HOW TO ASSEMBLE SADDLE
FIGURE 7
FIGURE 7 -
HOW TO ASSEMBLE PEDAL

