Diamondback 1280ef - Page 3

Main frame
Console supporting
tube
E1 Handle bar (L)
E2 Handle bar (R)
A
B
Front stabilizer
Rear stabilizerC
D
E
Central supporting tubeF
Console (G1)
&Console cover (G2)
G
Adaptor
I
Console supporting
tube cover (L&R)
L(A8)
R(A9)
Pedal supporting tube
cover (L1&L2),(R1&R2)
L1(A72)
L2(A73)
R1(A75)
R2(A74)
Front pedal supporting
tube cover
(A66)
(A67)
2
