Diamondback 64683 - Parts, Diagrams, and Warranty; Parts List

Page 17;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1Item 64683
EF;6GHIJ6KFGLIMNFLMG6MFMO6 E6GPJ
J,($ U*#4("/$"&8 h$V
1 Pan Head Tapping Screw ST4.8 x 13 10
2 Motor End Cover 1
3 Waterproof Board 1
4 Carbon Brush Cover 2
5 Depth Lock Knob 1
6 Depth Lock Pin 1
7 Rubber Seal Ø6.7 x 1.8 1
8 Flat End Set Screw M5 x 10 4
9 Bevel Angle Bracket 1
10 Bevel Angle Pointer 1
11 Flat Washer Ø5 23
12 Spring Washer Ø5 5
13 Pan Head Screw M5 x 10 5
14 Pan Head Screw M5 x 16 5
15 Motor Housing 1
16 Carbon Brush 2
17 Carbon Brush Holder 2
18 Power Cord Clip 1
19 Damping Ring 1
20 Deep Groove Ball Bearing 608-2RS 1
21 Armature Assembly 1
22 Stator Assembly 1
23 Flat Washer Ø4 28
24 Pan Head Screw M4 x 60 2
25 Windshield 1
26 Large Flat Washer Ø10 1
27 Depth Knob 1
28 Lower Handle 1
29 Upper Handle 1
30 Pan Head Screw M5 x 25 4
31 Pan Head Screw M5 x 12 1
32 Inner Blade Guard 1
33 Water Hose Baffle 1
34 Water Nozzle Joint Angle Mandrel 1
35 Rubber Seal Ø12 x 1 2
36 Pan Head Screw M4 x 10 25
37 Water Nozzle Connector 1
38 Outlet Fitting 1
39 Side Splash Guard 1
40 Rear Splash Guard 1
41 Retaining Ring 1
42 Blade Guard Knob 1
43 Pan Head Tapping Screw ST4.8 x 13 1
44 Outer Blade Guard 1
45 Spindle Nut 1
46 Outer Flange 1
47 Saw Blade 1
48 Water Nozzle 2
49 Inner Flange 1
50 Inner Blade Guard Screw 1
J,($ U*#4("/$"&8 h$V
51 Body 1
52 Wool Felt 1
53 Oil Bearing 1
54 Large Gear Wheel 1
55 Shaft Ring 1
56 Stop Ring 1
57 Deep Groove Ball Bearing 6002-2RS 1
58 Spindle 1
59 Bearing Seat 1
60 Spring Washer Ø4 8
61 Table 1
62 Bearing Screw 5
63 Screw 2
64 Roller 3
65 Nut M8 12
66 Countersunk Head Screw M6 x 10 1
67 Bearing Washer 1
68 Bearing Screw 1
69 Table Stop 1
70 Miter Lock Lever 1
71 Screw 1
72 Miter Screw 1
73 Miter Body 1
74 Miter Base 1
75 Nut M6 3
76 Miter Base Plate 1
77 Water Tray 1
78 Water Pump 1
79 Miter Gauge Lock Knob 1
80 Compression Spring 1
81 Steel Ball Ø6 1
82 Water Hose 1
83 Table Lock Lever 1
84 Steel Ball Ø6 1
85 Compression Spring 1
86 Eccentric Screw 4
87 Friction Sleeve 4
88 Lock Nut M6 4
89 Bearing Screw 3
90 Retaining Ring 3
91 Hex Key 1
92 Bearing 608-2RS 6
93 Bearing Washer 3
94 Roller 3
95 Screw Sleeve 1
96 Screw 1
97 Compression Spring 1
98 Bevel Lock Lever 1
99 Lock Bolt 1
100 Flat Washer Ø8 14
J,($#%T"#$%,89%U",3(,5
J,($#%T"#$
