Dickson PB-101 - Parts List

Instructions for Operation and Care of Dickson Paraffin Baths
WHITEHALL MANUFACTURING • P.O. BOX 3527 • City of Industry, CA 91744-0527 U.S.A
Phone (800) 782-7706 • (626) 968-6681 • Fax (626) 855-4862 • Web: www.whitehallmfg.com
10
WHITEHALL PART #
DESCRIPTION
PB-101 See page 12
PB-107 See page 13
PB-104 See page 14
PB-105 See page 15
PB-101B See page 12
PB-107B See page 13
PB-104B See page 14
PB-105B See page 15
1 5902-111-399 Cover, Stainless Steel x x x x
2 6902-306-000 Cover, Plastic x x
3 6902-412-000 Cover, Plastic (Front Se ction) x x
4 6902-410-000 Cover, Plastic (Rear Secti on) x x
5 6902-308-000 Drain Insert x x x x
6 6902-350-000 Drain Valve x x x x
7 6902-130-001 Element, Heating 120V x x
8 6902-136-001 Element, Heating 220V x x
9 6902-327-000 Element, Heating 120V x
10 6902-330-000 Element, Heating 220V x
11 6902-438-000 Element, Heating 120V x
12 6902-439-000 Element, Heating 220V x
13 0710-230-001 Fuse Holder/Cap x x x x x x x x
14 6902-132-000 Fuse, 4 Amp x x x x
15 0710-212-000 Fuse, 6.3 Amp x x
16 0710-216-000 Fuse, 10 Amp x x
17 6900-130-000 Knob For Timer or Switch x x x x x x x x
18 6900-135-000 Light, Rectangle (Green) 125VAC x x
19 6900-137-000 Light, Rectangle (Green) 250VAC x x
20 6902-346-000 Light, Rectangle (Red) 125VAC x x
21 6902-347-000 Light, Rectangle (Red) 250VAC x x
22 6902-122-000 Light, Square (Green) 125VAC x x
23 6902-119-000 Light, Square (Green) 250VAC x x
24 6902-124-000 Light, Square (Red) 125VAC x x
25 6902-121-000 Light, Square (Red) 250VAC x x
26 6902-123-001 Power Cord (Assembly) 120V x x
27 220 V Power Cord (Assembly) 220V x x
See parts diagrams on pages 12 through 15 for corresponding numbers in
the first column of the above table. The table continues on page 11.
PARTS LIST FOR DICKSON PARAFFIN BATHS
