Dickson PB-101 - Parts List

Instructions for Operation and Care of Dickson Paraffin Baths
WHITEHALL MANUFACTURING • P.O. BOX 3527 • City of Industry, CA 91744-0527 U.S.A
Phone (800) 782-7706 • (626) 968-6681 • Fax (626) 855-4862 • Web: www.whitehallmfg.com
11
See parts diagrams on pages 12 through 15 for corresponding numbers in
the first column of the above table. The table starts on page 10.
PARTS LIST FOR DICKSON PARAFFIN BATHS
Continued from
previous page
WHITEHALL PART #
DESCRIPTION
PB -101 See page 12
PB-107 See page 13
PB-104 See page 14
PB -105 See page 15
PB-101B See page 12
PB -107B See page 13
PB-104B See page 14
PB-105B See page 15
28 6900-116-001 Power Cord (Assembly) 120V x x
29 220 V Power Cord (Assembly) 220V x x
30 6902-270-001 Resistor Assembly, 3K - 120V x
31 6902-271-001 Resistor Assembly, 12K - 220V x
32 6902-370-001 Resistor Assembly, 3K - 120V x
33 6902-371-001 Resistor Assembly, 12K - 220V x
34 6902-470-001 Resistor Assembly, 3K - 120V x
35
6902-471-001 Resistor Assembly, 12K - 220V x
36 6902-374-000 Slat, Plexiglass x x
37 6902-424-000 Slat, Plexiglass x x
38 6505-520-000 Strain Relief x x x x x x x x
39 6902-126-000 Switch (Temperature) x x
40 6902-138-000 Thermometer x x x x
41 6902-139-000 Thermometer, Celsius x x x x
42 6902-310-000 Thermometer (2”) x x x x
43 6902-314-000 Thermometer, Celsius (2”) x x x x
44 6902-140-000 Thermostat, Capillary (Operating) x x x x x x x x
45 6903-146-000 Thermostat, L-145 x x x x x x
46 6902-144-000 Thermostat, L-200 (High Limit) x x x x x x x x
47 6902-348-000 Timer, Mechanical x x x x x x
